5.15 Reset of the remote control
Fig. 38: Reset of the remote control
5.16 Operation at the air distributor
2
3
Fig. 39: Display on the air distributor
1. Touch key
2. Operation mode symbols
3. Temperature display
5.17 Adjusting the air outlets
1
Fig. 40: Adjusting the air outlet
Cool Top Trail 20/24
To reset the remote control to factory settings take out the
X
batteries and put them back in.
– The clock will have to be set again.
– The timer is deactivated.
You can control the basic functions of the air conditioner with
the
1
the remote control is lost or does not function.
Press the touch screen key
X
each touch you cycle through the modes:
C
OFF
In cooling and heating mode the set point temperature is au-
tomatically set to 24°C and the fan speed is HIGH.
2
Use the remote control to select any other temperature or fan
speed.
At the air distributor you cannot select the "auto" mode, but
the display shows the "auto mode" in the right-hand top cor-
ner, once selected on the remote control.
The air distributor has adjustable air outlets (louvres) (1). The
blades can be moved to direct the air flow.
Adjust the direction and angle of the air outlet by moving
the blades around their axis. The blades move together.
1
key on the display on the air distributor. This is useful if
COOL
FAN
at the air distributor. With
HEAT
17
