3 - InSTallaTIon
Before installation, check strength and horizontality of the
base so that abnormal sound does not generate.
According to the dimensions and clearances, fix the base
firmly with the anchor bolts (Anchor bolt, nut: M10 x
2 pairs).
If the outdoor unit is installed in a very windy place,
protect the fan with a wind protection screen and check
that it works correctly.
3.1 - opening cable knockouts (fig. 4)
There is a pre-cut part that can be removed for running
wires. Do not remove the unit front panel for easier
drilling of theknockouts. The pre-cut section of the sheet
can be removedby punching the 3 connection points along
the line first using a screwdriver and finally with your
hands (See Fig. 4).
When the cable knockout is open, remove the burrs and fit
the cable protective bush supplied with the unit for cable
protection.
4 - dIMenSIonS and clearanceS
For dimensions see fig. 1
30rB
A
B
008-9008X9
908
821
012-9012X9
908
1363
015-9015X9
908
1363
Mimimum installation clearances in mm are shown in fig.2 (single installation) and fig. 3 (serial installation)
Mimimum Gross weight refers to the unit as shipped with packging. Net weight refers to unit with packaging removed.
NOTE: The height of the obstacle at both front and rear side should be lower than the height of the outdoor unit.
5 - SafeTy procedureS
5.1 - Servicing and maintenance
CAUTION:
•
Ensure adequate personal protective equipment is
used.
•
Extraordinary maintenance operations must be
carried out by specially trained personnel.
Disconnect the mains power supply prior to any
maintenance operations or prior to handling any internal
parts of the unit.
All manuals and user guides at all-guides.com
C
d
e
f
326
350
87
356
326
350
529
995
326
350
529
995
3.2 - How to remove the front panel (fig. 5)
1.
Remove screws of the front panel (See fig 5).
2.
Pull the front panel downward with the handle.
3.3 - unit fixing position (fig. 6)
See fig. 6.
For correct unit installation use the dimension indicated.
3.4 - operating limits (fig. 7)
Operation in cooling: See fig. 7
A- Outdoor air temperature (°C)
B- Outlet water temperature (°C)
g
h
l
Net weight
466
40
60
1105
44
69
1105
44
69
CAUTION:
•
This equipment contains refrigerant that must be
disposed of in a proper manner.
•
When disposing of the unit after its operational life,
remove it carefully.
•
The unit must then be delivered to an appropriate
disposal centre or to the original equipment dealer
for proper environmentally compatible disposal.
gross weight
75.5
82.5
73.5
80.5
114
121
108
114
116
123
110
116
17
