General description
The illustration of the principal
functionin g parts can be found
on the front foldout page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
Dispose of the packaging material prop-
erly.
• Cordless hand-held vacuum cleaner
• Wet nozzle
• Crevice nozzle
• Brush nozzle attachment
• Universal nozzle attachment
• Instruction Manual
Description of functions
The cordless hand-held vacuum cleaner is
equipped with a robust, transparency plas-
tic container for holding dirt.
Refer to the following descriptions for the
function of control elements.
Overview
3 Filter (HEPA)
4 Release button
5 On/off switch
10 Guide rail
11 Keyhole bore
Technical Data
Cordless hand-held
vacuum cleaner ................ PHSSA 20-Li A1
Nominal voltage U ......................20 V
Protection type................................. IPX0
Run time (idle) ........................16 - 20 min
Collection volume, maximum
Dust......................................... 400 ml
Liquid ...................................... 150 ml
Battery (Li-Ion) ...............PAP 20 A1
Battery cells ......................................... 5
Nominal voltage ......................... 20 V
Capacity ..................................... 2.0 Ah
Energy ..................................... 40 Wh
Charging time ...................... approx. 1 h
Temperature...........................max. 50 °C
Charging process ...................0 - 50 °C
Operation .......................... -20 - 50 °C
Storage .................................0 - 45 °C
Battery (Li-Ion) ...............PAP 20 A3
Battery cells ....................................... 10
Nominal voltage ......................... 20 V
Capacity ..................................... 4.0 Ah
Energy ........................................ 80 Wh
Charging time ...................... approx. 2 h
Temperature...........................max. 50 °C
Charging process ...................0 - 50 °C
Operation .......................... -20 - 50 °C
Storage .................................0 - 45 °C
Charger .............................. PLG 20 A1
Nominal consumption .....................65 W
Voltage input ............ 230-240 V~, 50 Hz
Voltage output ............... 21,5 V
Safety class ......................................
Miniature fuse ............................. T3.15A
Protection category........................... IPX0
GB
IE
; 2,4 A
II
15
