Koel-vrieskast
4
use
The control unit of the appliance is located in the appliance. Check that the voltage corresponds with what is stated on the
information plate.
Switching on the appliance
Insert the plug into the socket. All leds light up for 3 seconds.
The default setting of the appliance is 6 °C. The led for position 2 remains on.
Adjusting the temperature
By means of the thermostat you are able to change the temperature in the appliance.
The appliance has 4 positions, each with their own led:
Position/
Temperature
LED
cooler section
1
8°C
2
6°C
3
4°C
4
2°C
Set the temperature with the SETTING button. Each press of the SETTING button will change the temperature from top to
bottom. We recommend setting the appliance to position 3. The appliance will cool continuously until the set temperature
has been reached.
Allow the appliance to reach the set temperature, before filling it with food. Usually this will take 2 to 3 hours. After that, you
can set the thermostat to the required position and fill the appliance with food.
To switch off the appliance, remove the plug from the socket.
Super cool
Use the super cool mode when the appliance is getting warmer and no longer cools properly due to extremely hot weather,
frequently opening the doors or placing a large quantity of food in the appliance at once.
In order to restore the cold temperature, select the super cool mode.
When this mode is selected, the temperature of the cooler section will be lowered for a maximum period of 6 hours. After
this, the temperature returns to the preset temperature.
In order to set the super cool mode, press the SETTING button for 3 seconds. After 30 seconds, the super cool mode is
switched on and leds 1 and 2 light up.
To switch off the mode, press the SETTING button until the symbol no longer lights up.
Super freeze
Use the super freeze mode when the appliance is getting warmer and no longer cools properly due to extremely hot
weather, frequently opening the doors or placing a large quantity of food in the appliance at once.
In order to restore the cold temperature, select the super freeze mode.
When this mode is selected, the temperature of the freezer section will be lowered for a maximum period of 24 hours. After
this, the temperature returns to the preset temperature.
In order to set the super freeze mode, press the SETTING button for 5 seconds. After 30 seconds, the super freeze mode is
switched on and leds 3 and 4 light up.
To switch off the mode, press the SETTING button until the symbol no longer lights up.
Note: use the super freeze mode if you want to freeze a lot of food at the same time. Freezing will go faster, the nutrients will
be preserved and you are able to store the food for a long time..
Attention:
The ambient temperature, the frequency of opening the door and the position of the appliance have an effect
on the temperature in the appliance. Take this into account when setting the thermostat.
• Do not place hot food in the appliance.
• You should never place hazardous, highly flammable or explosive substances such as alcohol, acetone or petrol
in the appliance, because there will be a hazard of explosion.
• Carefully package meat and fish to prevent unpleasant smells.
• Do not place food items in contact with the cold wall at the back of the appliance.
• Leave sufficient space between the different foods, to allow the air to circulate properly.
• Do not leave the door open for longer than necessary.
22
•
English
Temperature
freezer section
-16°C
-18°C
-22°C
-26°C
1
2
3
4
