N.B. – When performing the procedure, you can cancel the memorisation at any time by keeping the n and s keys pressed simultaneously for 4 seconds Alternatively,
do not press any keys and wait 60 seconds for the motor to complete 6 movements.
––– Procedure 5.9.2 performed using the Era P or Era W transmitter –––
01
Old
03
sec.
Old
5.10 - Total or partial deletion of memory
This procedure allows you to choose under point 05 the data that you want to delete.
5.10.1 - Procedure performed with a transmitter memorised in "Mode I"
Before starting the procedure, move the shutter/awning to the mid-point of its stroke.
01. Keep the n key pressed and wait for the motor to perform 2 movements. Upon completion, release the key.
02. Keep the s key pressed and wait for the motor to perform 3 movements. Upon completion, release the key.
03. Keep the n key pressed and wait for the motor to perform 3 movements. Upon completion, release the key.
04. Keep the t key pressed and wait for the motor to perform 3 movements. Upon completion, release the key.
05. • To cancel the entire memory: Keep the s and t keys pressed and wait for the motor to perform five movements. Upon completion, release the keys.
• To delete only the memorised transmitters: do not press any key and wait until the motor performs five movements.
• To cancel just the parameters: keep the n key pressed and wait for the motor to perform 5 movements. Upon completion, release the key.
01
5
sec.
04
5
3
sec.
N.B. – When performing the procedure, you can cancel the memorisation at any time by keeping the n and s keys pressed simultaneously for 4 seconds Alternatively,
do not press any keys and wait 60 seconds for the motor to complete 6 movements.
7 – English
PRG
6
2
sec.
x 1 = Passo-passo
x 1 = Step-by-Step
x 2 = Apri > Stop > ...
x 2 = Open > Stop > ...
x 3 = Chiudi > Stop > ...
x 3 = Close > Stop > ...
0,5
x 4 = Stop
x 4 = Stop
02
2
02
PRG
...
2
04
1 /
2 /
3 /
10
?
sec.
4 /
5
3
sec.
05
all
mem-
ory
05
only
...
05
pa-
ram-
eters
PRG
6
2
sec.
New
example
5
sec.
New
03
5
3
sec.
5
5
sec.
5
5
5
sec.
PRG
3
