Initial operation
Location
• When installing the device, make sure to keep a distance of at
least 50 cm between the unit and any walls or other objects.
• The surface must be flat and dry.
Assembly of exhaust pipe
NOTE:
For sliding windows, you may use the window kit provided and
install it in a vertical or horizontal position. Adjust the length of
the seal plate as desired.
1. Turn the adapter (8) to one end of the exhaust pipe.
2. Connect the exhaust pipe to the unit using the exhaust pipe
connector. Turn the pipe anticlockwise several times. Make
sure the pipe is securely connected.
3. Extend the pipe to the desired length.
4. Stick the open end of the pipe into a window.
5. Close the window as far as possible. Also lower any external
roller blinds, if present, to the end of the pipe.
Remote control
1. Open the battery compartment cover on the back of the
remote control.
2. Insert 2 batteries of type R03 "AAA" 1.5 V, observing the cor-
rect polarity (see markings on the bottom of the compartment)!
3. Close the battery compartment cover.
Mains connection
1. Make sure the mains voltage you want to use corresponds to
the voltage of the unit. Please check the rating label for de-
tailed specifications.
2. Connect the unit to a properly installed grounded socket. A
signal will sound indicating that the unit is ready for use. The
display will show the current room temperature with low illumi-
nation.
Using the Appliance
Turning unit on/off
• Press the POWER
button to turn on the unit. During ini-
tial operation, the display will show the default setting
"Cooling" and 22 °C. If operation has been stopped without
disconnecting the plug, all previously set operating mode and
temperature settings will be retained. In that case, the display
will show these settings instead.
• Press the POWER
button again to turn off the device. The
display will again show the current room temperature with low
illumination.
Operating modes
Use the MODE
button to select one of the following operating
modes:
• Cooling
• Dehumidifying
• Fan
The display will show the respective icon.
All manuals and user guides at all-guides.com
Setting the temperature
Use the UP
the temperature. Select a temperature between 16°C and 31°C.
Setting the fan
In "Cooling"
with 2 different settings. Press the VENTILATOR
cordingly.
Setting the air outlet
Adjust the fins to regulate the direction of discharged air.
• Use the lever (1) to adjust the fins to the right / left.
• Turn one of the fins in order to direct the air upwards / down-
Setting the sleep mode
• When in "Cooling"
• After one hour of operation the system will increase the pre-
• In sleep mode, the fan operates at the lowest speed setting.
• Sleep mode cannot be activated when in "Dehumidifying"
Dehumidifying
• This operating mode does not support any further settings.
• The fan will operate at the lowest speed setting.
• After approx. 3 minutes of operation the compressor will turn
• The unit will cool the room and extract the humidity from the
Timer (Automatic timer)
Use the timer function to set the power-on and power-off times of
the device. Select a time between 1 and 24 hours.
Using the timer function for automatic power-on
1. Press the POWER
for
2. Select the operating mode, temperature and fan speed for the
3. Press the POWER
4. Press the TIMER
Using the timer function for automatic power-off
1. Press the POWER
2. Press the TIMER
• In order to deactivate the timer function, use the
or DOWN
buttons in "Cooling"
and "Fan"
modes you can set the fan speed
wards.
mode, use the SLEEP
activate the sleep mode.
viously selected temperature by 1°C. After another hour of
operation the system will increase the temperature again by
1°C. There will be no further adjustments after that.
This setting cannot be changed.
mode.
on and the display will in addition show the
air.
button to turn on the unit.
unit to operate in or at when powered on at the pre-set time.
button to turn off the unit.
button repeatedly to set the hour as
desired. The display will show the
which the unit will power on automatically.
button to turn on the unit.
button repeatedly during operation to
set the hours as desired. The display will show the
The hours after which the unit will power off automatically, will
briefly flash.
NOTE
and select "00".
mode to set
button ac-
button to
icon.
icon and the hours after
icon.
button
33
