Intended use
Caution!
Operator must know local regulations for emptying a holding tank.
3.3
Features
Secure discharge pump control. Key-operated switch provides convenient means to secure
discharge pump operation without use of padlocks or other mechanical fasteners .
Helps prevent pump burn-out. Activated panel light indicates when discharge pump is operating .
Reminds operator to shut off pump when tank discharge is complete .
Automatic pump shut-off with DTM04 tank monitor system. Discharge pump stops when tank level
drops below "Empty" level probe (fig . 6 4, page 4) .
Simplifies plumbing system. Eliminates wye valves, seacocks and vented loops of multiple
toilet systems .
4
Components
Items in fig.
Description
1
1 page 2
1
Replacement key
2
Switch assembly
3
Panel cover
4
#6 fastener
5
Mounting frame
6
Circuit assembly
7
Circuit assembly housing
5
Specifications
5.1
Materials
Panel frame and mounting frame: ABS
Circuit assembly housing: High-density polyethylene
5.2
Electrical Current Draw (panel only)
System Voltage
12 V DC
24 V DC
Specifications subject to change without notice .
6
All manuals and user guides at all-guides.com
6
Panel surface: Polycarbonate resin
Pump Off (amp)
0
0
Dometic Tank Discharge Control
Item Number (Europe / North America)
860003853110362 / 385311036
860003853116104 / 385311610
860003853116112 / 385311611
860003853116120 / 385311612
860003853116138 / 385311613
860003853116146 / 385311614 – 12 V DC
860003853116153 / 385311615 – 24 V DC
860003853116161 / 385311616
Pump On (amp)
0 .16
0 .095
