5451370-Akku-Bohrs-man 30.01.14 07:12 Seite 40
GB
Operating instructions & safety hints
WARNING! To reduce the risk of injury, please read the operating instruc-
tions through carefully before using the device, and then store with the
machine! When passing the device on to another user, these operating
instructions must also be included!
Contents
instructions
the equipment
1 - Scope of delivery
• Cordless Drill & Screwdriver
• 1 Rechargeable battery
• Charger
• Mains adapter
• 2 double bits, 45 mm
• Tool box
• Operating Instructions
• Guarantee
2 - Technical information
Technical data
Motor
Speed
Torque
Drill diam Ø
- Wood
- Aluminium
ø max.
Chuck
40
All manuals and user guides at all-guides.com
Page
40
40
41
41
42
45
18 V - . ..
-1
n
I = 0 -400 min
0
-1
II = 0 -1200 min
max. 30 Nm
23 mm
8 mm
10 mm
max. 10 mm
18 V - . .. /1500 mAh
Charger
Typ JLH082250370G
Prim: 100-240 V~/
50-60 Hz/12 W
Sek: 22,5 V - . .. /370 mA
Charging time ca. 3-5 h
Technical changes reserved.
Noise emission/vibration
Noise emission
L
: 83 dB(A)
pA
L
: 94 dB(A)
WA
Measuring inaccuracy:
K
: 3,0 dB
pA
K
: 3,0 dB
WA
Hand/arm vibrations
2
a
: 1,23 m/s
;
hD
When drilling into metal a
Measuring inaccuracy K: 1,5 m/s
Page
46
48
48
49
50
2
: < 2,5 m/s
;
h,D
2
