AVENAR keypad 8000
Notice!
i
Do not use tools with sharp edges (e.g. screw drivers or pens)
to operate the device or its touchscreen.
Notice!
i
The device may not be exposed to direct sunlight.
Notice!
Touchscreen recalibration is required to be performed at least
i
once a year. Otherwise operating the device may be difficult or
even not possible without prior re-calibration. For further
information, see the necessary procedure in the user guide.
Notice!
i
Painted surface. Handle with care to prevent damage. Clean the
surface only with a slightly damp soft cloth.
2
Functional Description
The Remote Keypad can be used to perform the same operating
procedures as the control panel, enabling variable operation of a
networked system. It has the following functional elements (see
01, page 4 ):
Pos. Designation
A
Interfaces
B
Touchscreen
C
6 fixed
buttons
D
Memory card
slot
Bosch Sicherheitssysteme GmbH
Function
CAN1, CAN2, IN1/2, Rail
Operating the networked system through virtual
buttons and variable display windows
Standard entries
Memory card reader for maintenance services
Functional Description | en
2022-12 | 09 | F.01U.347.558
