OPERATIOn
Pull the inner console out of the jacket until the black
■
lock icon completely disappears from the window.
Turn on the laser and select the laser beam mode you
■
wish to use.
Allow the pendulum to self-level before marking level
■
lines on a target surface.
PLUMB/CROSS LASER MODES
Crosshair beam mode -
The crosshair laser beam projects both a vertical and
horizontal line with plumb dots above and below the unit.
All manuals and user guides at all-guides.com
IT
nL
PT
DK
SE
See Figure 4a
FI
nO
RU
PL
CZ
English
Horizontal beam mode -
In horizontal beam mode, the beam is oriented for leveling
items horizontally, with a plumb dot directly above.
Vertical beam mode -
In vertical beam mode, the laser beam is oriented for leveling
items vertically, with a plumb dot below the unit.
Plumb bob mode -
In crosshair beam mode, the plumb/cross laser generates a
vertical upper and lower plumb dot. It can be used as a laser
plumb bob.
8
HU
RO
LV
LT
EE
See Figure 4b
See Figure 4c
See Figure 4d
