Ryobi TEK4 RP4000 Gebruikershandleiding pagina 15
Microkruislaser
gB
FR
DE
ES
OPERATIOn
OUT-OF-LEVEL InDICATOR
The plumb/cross laser is designed for accuracy when the
unit itself is not tilted more than 5°. If the unit is tilted more
than 5°, the laser will automatically shut off, to prevent
inaccurate readings.
A white backlight appears in the top laser aperture area to
indicate that the auto-leveling feature is enabled. If the unit
is out of level, the white light will blink continuously until this
is corrected.
FInE HEIgHT ADJUSTMEnT
To select the height of the beam, pull the adjustment lever
and slide the unit up or down in its jacket.
All manuals and user guides at all-guides.com
IT
nL
PT
DK
SE
FI
nO
RU
PL
CZ
English
For fine-tuning the height of the beam, turn the height
adjust-ment screw in the direction indicated.
LOW BATTERY InDICATOR
The low battery indicator on top of the unit will flash when
the battery needs to be recharged.
9
