Hama 00052883 Gebruiksaanwijzing pagina 5
Warning - connecting devices
• Before connecting a device, check
whether it can be adequately
supplied with the charger's current
capacity.
• Ensure that the power of the
connected device does not exceed
30W (18W + 12W).
• Note the instructions in your device's
operating manual.
Note - Power Delivery /
QC 3.0, 2.0
• Plug & GO: no additional software
required, simply plug in and start:
Thanks to Power Delivery / QC 3.0,
2.0, the voltage and power are
adjusted automatically.
• Be aware that, for e cient and
optimised charging, your terminal
device must support the PD (Power
Delivery)/QC 3.0, 2.0 function.
• If you have a large number of PD/
QC-enabled devices with different
rmware updates, it may be that the
function is not fully supported.
Unless different instructions have
been expressly given in the operating
instructions for the devices you are
charging, proceed as follows:
• Connect your device to the charger.
• Then connect the charger to the on-
board electrical system's car socket.
• The charging process is displayed on
your device.
• Disconnect the device from the charger
if you wish to interrupt the charging
process or when the device is fully
charged.
• Then disconnect the charger from the
line connection.
When charging the rechargeable batteries
in the device, note the maximum charging
times for the built-in batteries.
Note - car battery
With some vehicles, it can happen that
power continues to be supplied even
though the ignition has been switched
off. You should therefore disconnect
the product from the line connection
when not in use to protect your car
battery from being drained.
5. Care and maintenance
Only use soft, dry towels to clean the
product.
Note
Disconnect the device from the mains
before cleaning and during prolonged
periods of non-use.
6. Technical data
Car charger
Vehicle
electrical
system
voltage
5.0 V DC / 2.4 A / 12.0 W
Output
voltage /
5.0 V DC / 3.0 A / 15.0 W
current
9.0 V DC / 2.0 A / 18.0 W
max.
12.0 V DC / 1.5 A / 18.0 W
Output
power
total
7. Warranty disclaimer
Hama GmbH & Co KG assumes no liability
and provides no warranty for damage
resulting from improper installation/
mounting, improper use of the product
or from failure to observe the operating
instructions and/or safety notes.
12 V, 24 V
USB-A:
USB-C:
+ QC 2.0 / QC 3.0
30 W max.
3
