EN
PROGRAMS TABLE
Programs description
Eco 50°- program is suitable to clean normally soiled ta-
bleware, that for this use, it is the most efficient program
in terms of its combined energy and water consump-
tion, and that it is used to assess compliance with the EU
Ecodesign legislation.
Auto Intensive 65° - Automatic
program for heavily soiled dishes
and pans.
Auto Mixed 55° - Automatic pro-
gram for normally soiled dishes
with dried food residues.
Auto Fast 50° - Automatic program
for normally and lightly soiled dish-
es. The everyday cycle that ensures
optimal cleaning and drying perfor-
mance in shorter time.
Rapid 45° - Program is recommended for limited amount
of lightly-soiled dishes with no dried food residues. Does
not include the drying phase.
Crystals 45° - Program for delicate items, which are more
sensitive to high temperatures, for example glasses and cups.
Prewash - Use to refresh crockery planned to be washed
later. No detergent is to be used with this program.
Self-Clean 65° - Program to be used to perform mainte-
nance of the dishwasher and water management system,
to be carried out only when the dishwasher is EMPTY using
specific detergents designed for dishwasher maintenance.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration by up to 20 min.
OPTIONS AND FUNCTIONS
OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator
lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED flashes rap-
idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.
POWER CLEAN® - Thanks to the additional power jets this option
provides a more intensive and powerful wash in the lower rack, in the
specific area. This option is recommended for washing pots and casseroles
(Please refer to the Power Clean® loading section.
HALF LOAD - If there are not many dishes to be washed, HALF LOAD is
used to save water, electricity or time, depending on the selected
program. Remember to halve the amount of detergent.
EXTRA DRY - The higher temperature during the final rinse and the
extended drying phase allow improved drying. The EXTRA DRY option
results in the lengthening of the wash cycle.
SILENT - Suitable for night-time operation of the appliance. This option
can be used to limit noise emission during wash phases. It will increase
cycle time depending on base cycle selection.
SANI RINSE - This option can be used to sanitize washed dishes. It will
increase the final rinse temperature and add antibacterial wash to the
selected program. Ideal to clean crockery and feeding bottles. The dishwasher
door must be kept shut for the entire duration of the program in order to
guarantee reduction of germs. WARNING: the crockery and plates could
be extremely hot at the end of the cycle.
TURBO - Thanks to the Turbo option you can reduce time up to 40%
depending on the selected based program. Energy and water
consumption are increased.
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a program has been started.
2
Senses the level of
soiling on the dish-
es and adjusts the
program according-
ly. When the sensor
is detecting the soil
level an animation
appears in the dis-
play and the cycle
duration is updated.
-
-
-
-
Please scan the QR code on your product in order to have more detailed information.
Available
options
*)
TIME ON THE FLOOR - A LED light projected on the floor indicates the
time left to the end of the cycle. The light goes off every time the door
is opened. The light goes off at the end of a cycle.This feature is active
by default, but it is possible to deactivate it in the "SETTINGS MENU".
NaturalDry - It is a convection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying perfor-
mance every day. Door opens at the temperature that is safe to your kitch-
en furniture, thus door will not be opened when the option of SANI RINSE
is on. As additional steam protection, special designed protection foil is
added together with the dishwasher.
DESCALE – Alarm - Limescale accumulation was detected on the
internal components of the appliance. Check if the Water Hardness
Setting is at the correct value and salt is present in the salt container (see
FIRST TIME USE), then use a descaling product (WPro brand is recommended)
with Self-Clean program. After a successful descaling, the icon will stop
being displayed.
If the actions above are not performed, product performance will deteriorate.
DESCALE warning will start blinking and «dES» alarm will appear on the
display. If still no action is taken, the appliance will only allow a certain
number of cycles to be started (indicated during «dES» alarm display)
and then will be BLOCKED to prevent component damage, with only
the Self-Clean program available. Performing a full descaling will unblock
the product. In the case of extremely high amounts of limescale, descaling
may have to be performed twice to be efficient.
WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or
water tap is closed.
Quick Guide
Duration
Water
Energy
of wash
consumption
consumption
program
(litres/cycle)
(kWh/cycle)
(h: min)
**)
5:45
9.5
2:25 - 3:10
15.5 - 24.5
1.30 - 1.70
1:20 - 3:00
7.5 - 19.5
0.75 - 1.20
1:00 - 1:50
7.5 - 15.5
0.70 - 1.10
0:30 - 0:40
10.0 - 12.0
0.55 - 0.65
1:40 - 1:50
12.5 - 16.5
0.95 - 1.20
0:12
4.5
1:40
11.0
0.50
0.10
1.10
