EN
Installation
General starting points for installation
Perform the following steps before starting
installation.
1. Stop valves must already be installed.
2. If the water pressure is above the 5 bar, use
a pressure reducing valve (3 bar).
3. Close the stop valves.
4. In existing installations, remove the tap,
hoses and boiler if still in place.
5. Mark the existing cold and hot water
connection.
6. There must be two wall plug sockets
available for connection.
Install the pressure relief valve as high as
possible in the kitchen cabinet.
Installation steps
1. Installing 3-in-1 tap (see page 14)
2. Installing filter (see pages 15)
3. Installing pressure relieve valve (see page 16)
4. Connecting drain hose (see page 17)
5. Installing boiler (see page 17)
6. Installing Hydraulic Box (see page 17)
7. Connecting Hydraulic Box (see page 18)
8. Connecting tap (see page 18)
9. Activating Hydraulic Box (see page 19)
10. Flushing boiler (see page 20)
11. Activating boiler (see page 20)
12. Installing with WWS (see pages 21, 22, 23
and 24)
13. Installing with Bypass (see pages 25, 26
and 27)
14. Commissioning (see page 28)
12
