Manual device nr
This vacuum device works on a battery and is suitable for lifting glass or other sheet
material with a smooth surface and a dense structure TWIN500.
The maximum permissible weight is 500 kg and is marked on the appliance, this stated
-
weight only applies to a dry and untreated surface. With a damp or treated surface, the
maximum lifting weight can be greatly reduced.
The installation is equipped with a tank, each of which provides for at least 10 minutes of
-
vacuum in case of power source failure, if the underpressure in the tank drops below -0.6
bar, the acoustic signal will go into operation. Do not hoist during the signal.
There is a steel protective box around the aeration valve built.
-
Vertical lifting is the most unfavorable, therefore all tests are carried out vertically with
-
100% overload.
The vacuum gauge is colored red / green, so you can read it properly.
-
This machine is equipped with a double vacuum system, if 1 system fails, the 2nd system
-
will keep the load.
The machine is equipped with a dual vacuum system, if one system fails the second
-
system will hold the load.
Do not lift In rain and frost
-
In case of strong winds do not lift or guide the load to the best possible / guide through
-
cables / cords
The device is suspended from a hoisting hook with the lifting eye, this lifting hook must
-
be equipped with a safety valve
-
Always make sure that you are in sight or hearing distance of the device
-
The higher the load, the larger the area you need to clear
-
If the power is off there is a risk that the user can get vacuum with a vacuum residue from
the reserve tanks. Even though the vacuum gauges will remain in the red area, you will
not get a signal. So take care that the device is turned on at all times.
-
When hoisting profiled sheet there is no risk. If the profile is too sharp or deep vacuum
will not arise so you cannot lift and therefore avoid any dangerous situation. We advise
you therefore to carry out a test with the material to be lifted in a small size. It is also
possible to apply a different type of rubber edge so that there is created a vacuum. Call
us for more information
-
The lifting equipment must be stiff enough so it's not too far to bend or even nods. If this
is the case, it is necessary to choose a different suction cup.
Issue date:
Safety features on this device:
Warnings:
construction year:
