25. Do not touch the workpiece immediately after
operation; it may be extremely hot and could burn
your skin.
26. Always be sure that the tool is switched off and
unplugged or that the battery cartridge is
removed before carrying out any work on the tool.
27. Observe the instructions of the manufacturer for
correct mounting and use of wheels. Handle and
store wheels with care.
28. Do not use separate reducing bushings or
adaptors to adapt large hole abrasive wheels.
29. Use only flanges specified for this tool.
30. For tools intended to be fitted with threaded hole
wheel, ensure that the thread in the wheel is long
enough to accept the spindle length.
31. Check that the workpiece is properly supported.
32. Pay attention that the wheel continues to rotate
after the tool is switched off.
33. If working place is extremely hot and humid, or
badly polluted by conductive dust, use a
shortcircuit breaker (30 mA) to assure operator
safety.
34. Do not use the tool on any materials containing
asbestos.
35. Do not use water or grinding lubricant.
36. Ensure that ventilation openings are kept clear
when working in dusty conditions. If it should
become necessary to clear dust, first disconnect
the tool from the mains supply (use non metallic
objects) and avoid damaging internal parts.
37. When use cut-off wheel, always work with the
dust collecting wheel guard required by domestic
regulation.
38. Cutting discs must not be subjected to any lateral
pressure.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.
FUNCTIONAL DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and
unplugged before adjusting or checking function on
the tool.
Shaft lock (Fig. 1)
CAUTION:
• Never actuate the shaft lock when the spindle is
moving. The tool may be damaged.
Press the shaft lock to prevent spindle rotation when
installing or removing accessories.
Switch action (Fig. 2)
CAUTION:
• Before plugging in the tool, always check to see that
the slide switch actuates properly and returns to the
"OFF" position when the rear of the slide switch is
depressed.
To start the tool, slide the slide switch toward the "I (ON)"
position. For continuous operation, press the front of the
slide switch to lock it.
To stop the tool, press the rear of the slide switch, then
slide it toward the "O (OFF)" position.
Indication lamp
For Models 9561CVR, 9562CVR, 9564CVR, 9565CVR
(Fig. 3)
For Models 9561CR, 9562CR, 9564CR, 9565CR (Fig. 4)
The indication lamp lights up green when the tool is
plugged. If the indication lamp does not light up, the
mains cord or the controller may be defective. The
indication lamp is lit but the tool does not start even if the
tool is switched on, the carbon brushes may be worn out,
or the controller, the motor or the ON/OFF switch may be
defective.
Unintentional restart proof
The tool does not start with the switch being lock-on even
when the tool is plugged.
At this time, the indication lamp flickers red and shows
the unintentional restart proof device is on function. To
cancel the unintentional restart proof, return the slide
switch to "O (OFF)" position, then release it.
Speed adjusting dial
For 9561CVR, 9562CVR, 9564CVR, 9565CVR (Fig. 5)
The rotating speed can be changed by turning the speed
adjusting dial to a given number setting from 1 to 5.
Higher speed is obtained when the dial is turned in the
direction of number 5. And lower speed is obtained when
it is turned in the direction of number 1.
Refer to the below table for the relationship between the
number settings on the dial and the approximate rotating
speed.
Number
1
2
3
4
-1
min
(R.P.M.)
2,800
4,000
6,500
9,000
9
