9.3 Appliance-specific information: Jannik Large-01
9.3.1 Outside air connection, air slide valve and flue gas exhaust
9.3.1.1 Outside air connection
The fire is made with an outside air connection. This outside air connection is supplied separately.
Assembly always takes place at the bottom of the appliance.
When mounting the outside air connection, please proceed as follows (see Appendix 2, fig. 10):
Ø
Loosen the 4 bolts that are pre-mounted on the outside air connection.
Ø
Bring the outside air connection against the plate on the bottom of the appliance.
Ø
Then re-tighten the 4 bolts.
Ø
Connect the flexible hose (Ø 80 mm) to the round 'pipe opening' of the outside air connection.
The flexible hose can be fed from the back and from the bottom.
In case of a Jannik Large-01, air supply is possible from the back of the appliance.
!Caution
For this purpose see Appendix 2, fig. 3.
9.3.1.2 Air slide valve
When installing and maintaining the appliance, please check the operation of the air slide valve
(see Appendix 2, fig. 11).
It is possible that steel grit entered the air slide valve during transport. If the air slide valve does not move
smoothly it must be cleaned. For this purpose, the air slide valve must be disassembled. The suspended air slide
valve is spring-mounted using a bolt and a spring, which are located below the cover plate.
When mounting the air slide valve, please proceed as follows (see Appendix 2, fig. 11):
Ø
Remove the vermiculite plates from the bottom (see section 9.3.2.1).
Ø
Hold the Allen screw at the top of the cover plate stationary using an Allen key, so it will not rotate as well.
Loosen the nut at the bottom at the same time.
As soon as the bolt has been loosened, the air slide valve will fall down. Make sure you catch the air slide valve!
!Caution
Ø
Check the air slide valve and clean it if necessary.
In order to replace the air slide valve, proceed as described for removal, only in reverse order.
9.3.1.3 Flue gas exhaust
The appliances described in this manual are supplied with a flue gas exhaust ring that can be turned around.
This will allow a connection with a diameter of 130 or 150 mm. At delivery, the appliance is provided with a
150 mm exhaust (see Appendix 2, fig. 12 and 13).
When turning around the flue gas exhaust (for a 130 mm diameter exhaust), proceed as follows:
Ø
Remove the flame baffle plate (see section 9.2.2.2).
Ø
Loosen the 2 nuts of the flue gas exhaust ring.
Ø
Remove the flue gas exhaust ring.
Ø
Loosen the three nuts of the 150 mm diameter flange.
Ø
Remove the flange (Ø 150 mm).
Ø
Turn the flue gas exhaust ring by 180° and then place it back.
Ø
Re-tighten the 2 nuts of the flue gas exhaust ring.
42
I N S T A L LA T I ON M A N U A L
