IN S TA LLA TION M A N U A L
9.3.2 Interior lining
9.3.2.1 Vermiculite
The fire's vermiculite plates are located on the bottom and against the rear and side walls of the appliance.
In the following situations the vermiculite plates must be taken out:
•
When disassembling the air slide valve (see section 9.2.1.2).
•
When replacing the vermiculite plates.
The bottom plates are removed first and the rear plates are removed last.
The insertion of the vermiculite plates takes place in reverse order.
Make sure the vermiculite plates are placed back in their original positions! The back plate, for instance, must be
!Caution
placed with the small, not countersunk, holes towards the front.
9.3.2.2 Flame baffle plate
On delivery the flame baffle plate is located in the top section of the appliance.
In the following situations the flame baffle plate must be taken out:
•
during general maintenance;
•
when installing or changing the position of the restrictor tray;
•
during maintenance to the restrictor tray;
•
when turning around the flue gas exhaust ring.
To do this proceed as follows:
Ø
Take hold of the flame baffle plate and push the right side upwards.
Ø
Slide the flame baffle plate over the ridge to the right.
Ø
Lower the left side of the flame baffle plate and remove the flame baffle plate.
Placing the flame baffle plate takes place in reverse order.
The stainless steel profile must be placed at the front with the screw heads facing the top (see Appendix 2, fig. 6).
!Caution
43
