| DEScRIPtIoN of tHE APPLIANcE
1
1. on/off button
- when the on/off button is pressed the control lamp in the Start/Pause button lights up.
2. Handle - use the door handle to open and close the door of the dishwasher.
3. Half load button
with control light - if you have a little amount of dishes in the dishwasher, you can activate the
button half load. The selected program takes less time. Which decreases your energy- and water consumption.
4. Start/ Pause button
selector knob will start and the control lamp Wash/Dry lights up.
5. control lamp for softening salt - the dishwasher checks if there is enough salt available. If not, the control lamp lights
up and you need to refill the salt reservoir.
6. control lamp for rinse aid - the dishwasher checks if there is enough rinse aid available. If not, the control lamp lights
up and you need to refill the rinse aid reservoir.
7. Indicator light Wash Dry - the indicator light will light up when the dishwasher is washing or drying.
8. Indicator light Ready - when the dishwasher has finished washing and drying this indicator light lights up.
9. Program selector knob - select the desired washing program with this knob.
2
3
4
5
6
with control light - once you press this button, the program you selected with the program
1
5 6
2
3 4
12
11
10
9
8
7
30
moDEL VVW6022A
7
8
9
1. Worktop
2. Upper basket
3. Upper spray arm
4. Lower basket
5. Cutlery basket
6. detergent and rinse aid reservoir
7. Control panel
8. Rating label
9. Filters
10. Lower spray arm
11. Salt reservoir
12. Upper basket track latch
