Diagram frameonderdelen LoBoy
104
Ref.
Onderdeel Omschrijving
100
867488
SCREW #6X.25 SLFTAP PH HD
101
867551
SCREW 6-32X1.25 PH PN HD
102
867329
NUT 6-32 X .109 TOP LOCK
103
GUN
289316
500,2 FINGER,ASM, (120V)
24E514
SPRAY, 009 (230/240V & 110V)
104
143029
COLLAR,SCREW,SET (SPE-
CIAL ID)
105
15B870
CUP,SUCTION/DRAIN
108
305039
SPACER,3/4 ID .50 LG PVC
109
331048
RUBBER BOOT
110
331103
WASHER .562 .250 .060 .ST
111
331171
FRAME WELD- LP-LB
184
866476
HANDLE,LB,SUBASSEMBLY
(Includes 184a, 184b, 184c, 184d)
184a 331174
HANDLE
184b 331222
PIN
184c 331175
SPACER
184d 331176
BUSHING
3A2172M
101
105
102
108
199
189
111
109
Aantal
Ref. Onderdeel Omschrijving
2
187
2
HSE1450 (120V)
2
865674
189 121112
1
199 867736
16F576
2
16F577
1
16K914
2
2
16K915
4
1
1
1
2
2
2
110
100
184
103
187
HOSE 1/4" X 50'
(230/240V & 110V)
SCREW,CAP, SOCKET HEAD
WHEEL-10" OD X3.5'W 150LB
LABEL, RIGHT, LP600 (not
shown)
LABEL, LEFT, LP600 (not
shown)
LABEL, RIGHT, LP500 (not
shown)
LABEL, LEFT, LP500 (not
shown)
Onderdelen
ti17480a
Aantal
1
1
4
2
1
23
