Zone
Cleaning products
Front panel
Hot water and a little soap:
Clean with a dishcloth and dry with a
soft cloth. Do not use a glass clean-
ing product or a glass scraper.
Stainless steel
Hot water and a little soap:
Clean with a dishcloth and dry with a
soft cloth. Immediately remove any
water marks, grease, cornflower or
egg white stains since corrosion
could occur underneath these marks
or stains.
Special products for the care of
stainless steel and which are suita-
ble for hot surfaces may be obtained
from Technical Assistance Service
centres and specialist retail outlets.
Use a very fine soft cloth to apply
the cleaning product.
Glass panel
Glass cleaning products:
Clean using a soft cloth. Do not use
a glass scraper.
Glass panels on oven
Glass cleaning products:
door
Clean using a soft cloth. Do not use
a glass scraper.
Oven interior
Hot water with a little soap or water
and vinegar:
Clean with a dishcloth.
If very dirty, use a stainless steel
scourer or special oven cleaning
products. These must only be used
when the oven interior is cold.
Glass cover for the oven
Hot water and a little soap:
light
Clean with a dishcloth.
The seal
Hot water and a little soap:
Do not remove!
Clean with a dishcloth. Do not rub.
Wire shelves or rails
Hot water and a little soap:
Soak and clean using a dishcloth or
brush.
Sliding guides
Hot water and a little soap:
Clean with a dishcloth or a brush.
Do not leave this to soak or wash in
a dishwasher.
Accessories
Hot water and a little soap:
Soak and clean using a dishcloth or
brush.
Light
The oven light can be turned on manually to facilitate cleaning.
Connecting the oven light
Turn the function control knob to the
The light will come on. The temperature control knob must be
turned off.
Turning the oven light off
Turn the function control knob to the
26
All manuals and user guides at all-guides.com
setting.
N
position.
Û
Removing and refitting the wire shelves or left
and right hand side rails
The wire shelves or left and right hand side rails can be
removed for cleaning. The oven must be cold.
Release the guides or rails
Lift the front of the guide or rail and release it (figure A).
1.
Then pull the guide or rail forwards completely and remove it
2.
(figure B).
Clean the guides or rails with detergents and a sponge. The
use of a brush is recommended for stubborn stains.
Install the wire shelves or rails
First insert the shelf or the rail in the rear groove by pushing it
1.
back slightly (figure A)
then insert it in the front groove (figure B).
2.
Wire shelves or rails can be adjusted on the left and right hand
side. Their curvature should always be face down.
Unhooking and hanging the oven door
The front panel can be unhooked to help remove the oven door
and clean the glass panels.
The oven door hinges are fitted with a locking lever. The door
cannot be unhooked if the locking lever is closed (figure A).
Once the locking lever has been opened to unhook the door
(figure B), the hinges will be locked in position. This prevents
the door from suddenly closing.
:
Risk of injuries.!
The hinges may close suddenly if they are not locked in
position by the lever. Note that the locking levers are always
closed, apart from when unhooking the door, when the levers
must be open.
