Unusual voltages/numbers of phases
Before connecting to voltages or numbers of phases not listed in
the wiring diagram Figure 12, contact Tylö Customer Service.
CONNECTION/WIRING DIAGRAM
TAB
400-415 V 3N~/3~
(C,D)
440 V 3~ (D)
Output
Amperage
Conductor
kW
amp
area mm²
6,6
10
1,5
8
12
2,5
Figure 12: Wiring diagram
1. Heater
2. Terminal for connection of electrical cable
CHECKING INSTALLATION
To check the installation:
1.
Switch on the mains supply to the heater from the distribution
board.
2.
Start the heater (see User Guide).
3.
Check that all three tubular elements start to heat up (go
red).
200-208 V 3~ (B)
Amperage
Conductor
amp
area mm²
19
4
23
6
1
2
1
A 3 x TAB
B 4 x TAB
C 5 x TAB
D 4 x TAB
230 V 3~ (B)
200-208 V~ (A)
Amperage
Conductor
Amperage
amp
area mm²
amp
17
4
33
20
4
40
400-415 V 3N~
Keep this user guide!
In the event of any problems, please contact the retailer where you pur-
chased the equipment.
© This publication may not be reproduced, in part or in whole, without
the written permission of Tylö. Tylö reserves the right to make changes in
materials, construction and design.
230-240 V~ (A)
Conductor
Amperage
Conductor
area mm²
amp
area mm²
10
29
10
16
35
10
