Ovanliga spänningar/fas-tal
Vid inkoppling till spänningar eller fas-tal, som inte anges i kopp-
lingsschema Fig 12, kontakta Tylö kundservice.
ANSLUTNING/KOPPLINGSSCHEMA
TAB
400-415 V 3N~/3~
(C,D)
440 V 3~ (D)
Eff ekt
Strömstyr-
Lednings-
kW
ka amp
area mm²
6,6
10
1,5
8
12
2,5
Fig 12: Kopplingsschema
1. Aggregat
2. Plint för inkoppling av elkabel
EGENKONTROLL AV INSTALLATION
För att kontrollera installationen:
1.
Slå på huvudspänning till aggregat från elcentral.
2.
Starta aggregatet (se Bruksanvisning).
3.
Kontrollera att alla de tre rörelementen går igång (blir röda).
200-208 V 3~ (B)
Strömstyr-
Lednings-
ka amp
area mm²
19
4
23
6
1
2
1
A 3 x TAB
B 4 x TAB
C 5 x TAB
D 4 x TAB
230 V 3~ (B)
200-208 V~ (A)
Strömstyr-
Lednings-
Strömstyr-
ka amp
area mm²
ka amp
17
4
33
20
4
40
400-415 V 3N~
