Abnormally
Time to end is calculated on the basis of:
elapsing time
type, volume and dampness of laundry.
5)
on the LCD
Programme in-
Full water reservoir.
active
Drying cycle to
Small laundry volume./Too dry laundry for
short
selected programme.
Fluff filters clogged.
To high loading volume.
Drying cycle to
Laundry insufficiently spun.
6)
long
Particularly high room temperature - no ma-
chine fault.
1) In case of error message on the LCD (e.g. E51- only dryers with the LCD): Switch the dryer off and on. Set
programme. Press the START PAUSE button. Does not work? - inform local service and quote the error
code.
2) follow program recommendation - see Programme overview chapter
3) see Care and cleaningchapter
4) see Machine settings chapter
5) only dryers with the LCD
6) Note: After around 5 hours the drying cycle ends automatically (see Drying cycle complete section).
Machine settings
Setting
BUZZER permanent off
Water hardness
Water contains, a variable
quantity of limestone and miner-
al salts of which quantities vary
according to geographical loca-
tions thus varying its conductivi-
ty values.
Relevant variations of the con-
ductivity of the water compared
to those prefixed by the factory
could slightly influence the re-
sidual humidity of the laundry at
the end of the cycle. Your dryer
allows you to regulate the sen-
sitivity of the drying sensor
based on conductivity values of
the water.
www.zanussi.com
1. Turn the programme selector to any programme.
2. Press simultaneously the Intensief (Intensive) and Lange anti-
kreuk (Long anticrease) buttons and hold down for approx. 5 sec-
onds.
3. The buzzer is by default always off.
1. Turn the programme selector to any programme.
2. Press simultaneously the Lange anti-kreuk (Long anticrease) and
Start/Pauze (Start/Pause) buttons and hold down for approx. 5
seconds. Lights show the current setting:
– Waterreservoir (Water Reservoir) - low conductivity <300 micro S/
cm
– Filter - medium conductivity 300-600 micro S/cm
– Condensor (Heat exchanger) - high conductivity >600 micro S/cm
3. Press the Start/Pauze (Start/Pause) button sequentially until you
set desired level.
4. To memorize setting press simultaneously the the Lange anti-kreuk
(Long anticrease) and Start/Pauze (Start/Pause) buttons or
turn knob to OFF position
Automatic process; this is not a machine
fault.
3)
Empty water reservoir
PAUSE button.
Select time programme or higher drying lev-
el (e.g. EXTRA DRY ).
Clean fluff filters.
Respect max. loading volume.
Spun adequately the laundry.
Lower the room temperature if possible.
Implementation
, press START
27
