EN
Insulation class adapter
Ingress protection code
Physical characteristics
Dimensions
Weight
Light intensity at Position 1
Light intensity at Position 2
Light intensity at Position 3
Spectral characteristics
Peak 1
Wavelength
Bandwidth
Peak 1
Wavelength
Bandwidth
Nominal Spectral irradiance
(100% intensity)
Maximal Spectral irradiance
(100% intensity)
Maximal variation of the output
Operating conditions
Temperature
Relative humidity
Atmospheric pressure range
Storage conditions
Temperature
Relative humidity
Expected service life
Device lifespan
Adaptor lifespan
18
II
IP20
17 x 16 x 3 cm
51 gr.
+- 500 lux
+- 1,000 lux
+- 1,500 lux
468 nm
70 nm
570 nm
100 nm
21,8 µW/cm
2
25,4 µW/cm
2
±7%
5 °C - +40 °C
15 % - 93 %
700 hPa - 1060 hPa
-25 °C - +70 °C
15 % - 93 %
6 years
3 years
B. Symbols
The following symbols may appear on the appliance:
Symbols
Description
Manufactured for : Lucimed SA,
Rue le marais 12a, 4530 Villers-le-Bouillet, Belgium
Tel : +32 4 369 48 36
Year of manufacture
Serial number
Consult the user manual supplied
This device should not be disposed of in the normal waste
stream but in an appropriate collection facility for recovery
and recycling
Carefully consult the user manual supplied
Protection degree against the entry of objects or water
Keep dry
The packaging of this device can be recycled
CE stands for European Declaration of Conformity. The code
1639 indicates that the notified body is SGS Belgium SA
Symbol for Standard 60601-1 signifying that the applied part
is BF type. The applied parts are the branches (right and left)
and the nose-adaptor
EN
19
