Wall mounting and minimum clearances
Mounting on the
wall
Fig. 1 Charger with optional wall bracket (DIN rail
Important! Observe minimum clearances for ventilation purposes. Ensure an adequate
supply of fresh air.
Floor installation
option
(1)
Fig. 3 Floor installation option
All manuals and user guides at all-guides.com
2
1
3
5
4
TS 35, EN 50022)
NOTE: If fixing to the wall, please note the weight of the charger. The bracket
must be fitted to a suitable wall using the correct dowels and screws.
(2)
(3)
(4)
> 3
0 m
m
5
Fig. 2 Minimum clearances
(1) Foot
(2) Catches
(3) Shims
(4) Screw 2.9 x 13
(1)
2
> 1
5 m
m
> 3
0 m
m
> 1
5 m
m
