6.1. Memory storage of DS radio controls
A maximum of two codes can be stored. One on the OPEN channel and one on the OPEN/CLOSE channel.
1.
On the DS radio control, select the required ON-OFF combination for the 12 dip-switches.
2.
On the control unit, press the push-button of the channel you wish to memory store, OP for the OPEN channel or O/C
for the OPEN/CLOSE channel.
3.
The relevant LED on the control unit begins to flash - release the push-button.
4.
On the radio control, press the push-button with which you wish to associate the selected channel.
5.
The LED on the control unit lights up on steady beam for about one second, signalling that the radio control was stored
in the memory, then it resumes flashing.
6.
To add other radio controls or memory store the second channel, repeat the operations from point 1
6.2. Memory storage of SLH radio controls
You can memory store up to a maximum of 250 codes, subdivided between the two channels, OPEN and OPEN/
CLOSE.
1.
On the radio control, simultaneously press and hold down push-buttons P1 and P2 (see radio control instructions).
2.
After about one second, the LED of the radio control begins to flash.
3.
Release both push-buttons.
4.
Press and hold down push-button OP or O/C on the board to respectfully memory store the OPEN or OPEN/CLOSE channel.
The relevant LED begins to flash.
5.
Simultaneously press the push-button of the radio control with which you wish to associate the selected command.
Check if the LED relating to the command being memory stored (DL7 for the OPEN channel or DL6 for the OPEN/CLOSE
6.
channel) lights up on steady beam for about two seconds to confirm correct memory storage.
7.
To finish programming, press twice in close succession, the push-button of the memory stored radio control.
The automated system will perform an opening manoeuvre - make sure that there are no obstacles inside the operating
range.
8.
To memory store the other channel, repeat all the procedure from point 1.
To add other radio controls, transfer the code of the memory-stored push-button of the radio control to the relevant push-button
of the radio controls to be added, repeating the memory storage procedure or observing the following procedure:
•
On the memory stored radio control, simultaneously press and hold down push-buttons P1 and P2 (see radio control
instructions).
•
The radio control LED begins to flash.
•
Release both push-buttons.
•
Put the two radio controls frontally into contact.
•
On the memory stored radio control, press and hold down the push-button relating to the channel you wish to transfer - the
radio control LED lights up on steady beam.
•
On the radio control to be memory stored, press the required push-button and release it after the radio control has flashed
twice.
•
To finish programming, press twice in close succession, the push-button of the memory stored radio control.
The automated system will perform an opening manoeuvre - make sure that there are no obstacles inside the operating
range.
6.3. Memory storage of LC/RC radio controls
You can memory store up to a maximum of 250 codes, subdivided between the two channels, OPEN and OPEN/
CLOSE.
1.
Use LC/RC remote controls only with receiver module at 433 MHz.
2.
On the control unit, press the push-button of the channel you wish to memory store, OP for the OPEN channel or O/C
for the OPEN/CLOSE channel.
3.
The relevant LED on the control unit begins to flash - release the push-button.
4.
On the radio control, press the push-button with which you wish to associate the selected channel.
5.
The LED on the control unit lights up on steady beam for about one second, signalling that the radio control was stored
in the memory, then it resumes flashing.
6.
During this stage further radio controls can be stored in the memory.
7.
After about 10 seconds, the control unit automatically exits the learning stage.
8.
To add other radio controls or memory store the second channel, repeat the operations from point 1
6.3.1. r
emote memory storAge oF
Other radio controls can be remotely stored only with the LC/RC radio controls, i.e. without using the push-buttons of the control
unit,, but using a previously stored radio control.
1.
Get a radio control already memory stored on one of the 2 channels.
2.
Step near to the automated system.
Press and hold down push-buttons P1 and P2 (see radio control instructions) simultaneously for about 5 seconds.
3.
4.
Within 5 seconds, press, on the memory stored radio control , the push-button you wish to transfer to the new radio control.
In this way the learning stage on the selected channel is activated on the control unit.
5.
Within 5 seconds, press, on the new radio control, the push-button you wish to associate with the selected channel.
6.
After the new radio control has been stored in the memory, the control unit keeps the learning mode active on the
selected channel for about 5 seconds.
7.
During these 5 seconds, other radio controls can be memory stored on the control unit, as ever associated with the
activated channel.
8.
When 5 seconds have elapsed from memory-storage of the last radio control, the control unit automatically exits the
