Technical Data (Subject to technical changes without notice. 24W16)
Precision (typical)*
Measurement range
(inside)**
Laser class
Laser wavelength
Speicher
Schutzart
Automatic switch-off
Power supply
Operating conditions
Storage conditions
Dimensions (W x H x D)
Weight
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for greater distances and under unfavourable measuring
conditions such as strong sunlight or weakly reflective target surfaces.
** at max. 5000 lux
EU and UK directives and disposal
This device complies with all necessary standards for the free movement
of goods within the EU and the UK.
This product, including accessories and packaging, is an electrical
appliance that must be recycled in an environmentally appropriate manner
in accordance with European and UK directives on waste electrical and
electronic equipment, batteries and packaging, in order to recover valuable
raw materials. Electrical devices, batteries and packaging do not belong in
household waste. Users are obliged by law to surrender used batteries or
battery packs to a public collection point, to sales outlets, or to technical
customer services, free of charge. Remove the battery from the device
without damaging it using standard commercial tools: arrange separate
collection before returning the device for disposal. Please do not hesitate
to contact the UMAREX-LASERLINER service department if you have any
queries regarding removing the battery. Look for information on local
disposal facilities and note the relevant disposal and safety information at
the collection points.
Further safety and supplementary notices at:
https://packd.li/ll/ans/in
DistanceMaster Plus 100
± 1,5 mm
0,05 m - 100 m
2 / < 1 mW (EN 60825-1:2014/
A11:2021 / EN 50689-1:2021)
635 nm
50 Speicherplätze
IP 65
30 sec laser / 3 min device
Li-Ion battery pack 3.7V / 0.7Ah
-10°C ... 40°C, max. humidity
20 ... 85% rH, no condensation, max.
working altitude 2000 m above sea level
-20°C ... 70°C,
max. humidity 80% rH
54 x 126 x 27 mm
122 g (incl. battery pack)
21
EN
