Introduction
The 2-Way WL Panda for LightSYS keypad enables communication between the wireless
keypad and a LightSYS control panel. Being bi-directional, the 2-Way keypad receives a
reply status indication from the panel for each command sent to the panel. You can operate
the keypad either using a code or a proximity tag.
Main Features
Bi-directional Wireless Communication
S.O.S / Two-way communication emergency key
Proximity tag operation
Double tamper protection (Box & Wall)
Battery economy mode
Communication Setup
The WL Panda for LightSYS keypad must identify itself to the system receiver. This can be
done by typing the 11-digit serial number of the keypad into the system or using RF mode.
Setup using RF communication
1.
From the Wired Keypad, navigate to the Programing (installer) menu, select 7)Install >
2)WL Device > 2)Allocation > 1)By RF > 3)Keypad and then press
2.
If there are two receivers allocated to the system, select the receiver you wish to allocate
and then press
3.
Select the Keypad location in the system and then press
4.
On the WL Panda for LightSYS Keypad you wish to allocate, send a Write message by
pressing both keys
display the Serial Number.
01/2019
simultaneously for at least 2 seconds; the keypad will
Page 3
5IN2812
