2. You may also rotate the handle as needed for comfort
(Fig. G3).
G1-1 Control Handle
G1-2
To Adjust the Control-Handle Tube Length
(Fig. H1, H2)
1. Release the quick-release lever (Fig. H1).
2. Move the blower tube to a comfortable operating
position within the adjustment zone (Fig. H2).
3. Engage the quick-release lever to secure the blower
tube in place (Fig. H2).
Quick-release
H1-1
H2-1
Lever
H2-2 Adjustment Zone
STARTING/STOPPING THE BLOWER
NOTE:
The blower may not properly start if the battery
pack or the blower temperature is -15°C or less. In this
case, remove the battery pack from the blower, allow
the battery pack and blower to warm up indoors for 10
minutes or longer. Reinstall the battery pack and try again.
Air-Speed Trigger (Fig. I1, I2)
◾
Depress the air-speed trigger to turn on the blower,
then the LCD screen will display the fuel gauge, battery
icon, and air speed indicator.
NOTE:
1 LED of the fuel gauge on the LCD screen flashes
when the battery charge is low.
◾
The air speed of the blower is controlled with the
variable speed trigger. More pressure on the trigger
results in higher blowing speeds; less pressure on
the trigger results in lower blowing speeds. Adjust the
speed to suit the task at hand. The corresponding air
speed indicator will display on the LCD screen.
◾
Release the air-speed trigger to turn off the blower. The
LCD screen will turn off within a certain period of time
after the trigger is released.
NOTE:
If a battery pack below 4 Ah is used, the air speed
is limited to two bars only.
Turbo Mode
While the air-speed trigger is depressed and held, press
the turbo button to increase the air flow to the maximum
velocity (Fig. I1). Both the turbo indicator and the fan icon
will illuminate on the LCD screen (Fig. I3).
56 VOLT LITHIUM-ION CORDLESS BACKPACK BLOWER — LBPX1100
NOTE:
The blower will return to the previous speed when
the turbo button is released.
Quick-release Lever
Speed Lock Mode
The speed lock can be used to operate the blower without
continuously pressing the air-speed trigger.
1. Depress the air-speed trigger until you reach the
desired speed (Fig. I1).
2. Press the speed lock button. The speed lock icon will
illuminate on the LCD screen (Fig. I4).
3. Then release the air-speed trigger, the blower will
keep running at "desired" speed.
NOTE:
Pressing the turbo button while in speed lock
Blower Tube
mode can lock the air speed at the maximum level. The
blower will resume the previous speed when you press
the turbo button once more.
4. To release the speed lock, press the speed lock
button again. The speed lock icon will disappear from
the LCD screen and the blower will turn off.
I1-1
I1-3
I2-2
I3-1
I4-1
LED LIGHT (Fig. J)
The LED light is located in the front of the control handle.
It provides illumination for increased visibility.
Press the LED light button once to turn the light on,
press it again to turn the light off. It will also turn off
automatically after approximately 5 minutes of blower
inactivity.
J-1
COMMUNICATION TECHNOLOGY
For information on our full range of connected products
and services, including connection instructions, please
scan QR Code below or visit
www.egopowerplus.eu/connect.
Turbo Button
I1-2
Speed Lock Button
Air-speed Trigger
I2-1
Fuel Gauge
Air-speed Indicator I2-3
Battery Icon
Fan Icon
I3-2
Turbo Indicator
Speed Lock Icon
LED Light Button
J-2
LED Light
EN
11
