3. Pull the starter handle (7).
4. If the motor starts slowly, re-
lease the starter handle into the
starter rope-guide (3).
For a warm start it is not neces-
sary to press the primer (30).
If the primer is pressed too often,
too much petrol will enter the car-
burettor and the motor is difficult to
start.
Motor stop:
•
Release the safety loop (2). The
motor switches off and the knife is
braked.
Knife stopping device:
Regularly examine the knife stopping
device: Release the safety loop (2). The
motor switches off and the knife is braked.
The knife must stop within 7 seconds.
Mowing
1. Start the engine (see
2. Hold the grip handle (1) and the
safety loop (2) with both hands
while mowing.
Working Instructions
General Working Instructions
• As far as possible, mow the lawn when
it is dry in order to protect the turf.
• Set the cutting height such that the
equipment is not overloaded.
• Run the equipment at walking speed
in lines that are as straight as possible.
For uninterrupted mowing, the lines
should always overlap by a few centi-
metres.
• Do not move backwards.
• On slopes, always work across the
slope.
• If the blade comes into contact with a
foreign body, switch off the engine im-
mediately. Wait until the blade is station-
ary and check the equipment for dam-
age. Restart work only if the equipment
is undamaged.
• Switch off the equipment during longer
breaks and for transportation and wait
until the blade is stationary.
• Clean the equipment after each use, as
).
described in the "cleaning and mainte-
nance" chapter.
Setting the Cutting Height
The equipment has 6 positions for set-
ting the cutting height (25-35-45-55-65-75
mm):
1. Pull the lever (17) outwards and
2. Push the lever (17) back in.
The correct cutting height is around
30 – 45 mm for an ornamental lawn and
around 40 – 65 mm for a utility lawn.
Select a greater cutting height for
the first cut of the season.
push it to the desired position
(31).
