7 ASSEMBLY
The grass trimmer is supplied with some components not assembled. To assemble these
proceed as follows:
7.1
Assembling the motor housing (Fig. 1)
Insert the motor housing (6) into the handgrip (5), make sure the cable between will not be
damaged.
7.2
Assembling the handle (Fig. 1)
Install the handle (4) onto the handgrip (5) with bolt and nut.
7.3
Mounting the guard
Align the reference indices of the body (6) of the spool holder (8) and of the guard (9). Insert
the guard in the body (up to the collar) and rotate it until the hole of the guard corresponds to
that of the body. Firm the screws supplied.
Caution! During this operation beware of the line cutter blade. You may be
wounded.
Caution! Never use the grass trimmer without the guard. It is vital for your
and other peoples' safety and for the good working order of the trimmer.
The failure to observe this safety regulation is not only dangerous but also
annuls the guarantee terms.
7.4
Use of the cable holder (Fig. 2)
The handle is equipped with a cable holder that serves for connection of the extension cable.
8 OPERATION
8.1
Hints for optimum use
If the trimmer is to be used for the first time, check that the nylon line touches or passes over
the cutting blade. The nylon line will be cut automatically when turn on the switch to the
maximum length. If it does not reach the necessary length, push the head of spool with your
finger while pulling the lines.
Insert the plug into the extension cable and attach it to the handle. Pressure the switch and
make the trimmer turn at no load; thus, the line length is automatically adjusted. Only
approach the implement to the grass to be cut while it is in operation, i.e. while the switch is
pressed down.
Caution! Before turn on the switch, take the blade cover away.
