Hold the appliance with both hands. Slowly move the appliance back and forth. When working
long grass proceed layer for layer. (Fig. 5) Keep the appliance away hard objects and plants.
Only use the appliance for working dry grass. When edging, guide the appliance over the edge
guide along the grass edge.
CAUTION! The short or worn line cuts less efficiently therefore, to improve
its operations, unplug the electrical supply and repeat the operation
described in the beginning of the chapter. These make sure that everything
is functioning properly and to familiarize yourself with the grass trimmer.
CAUTION! After switching off, the nylon line will continue to rotate for a few
more seconds.
8.2
Switching on and off
To switch the appliance on, keep the lock-off button de pressed and press the on/off switch.
To switch the appliance off, release the on/off switch.
8.3
Extending the line (Fig. 3)
To extend the line press the spool onto the ground whilst the motor is turning and the line will
extend automatically.
8.4
Replacement of the spool and line (Fig. 4)
▪
Unplug from the socket.
▪
Turn upside down the machine with the guard facing upwards.
▪
Hold with one hand the motor fan and the lower part of the spool firmly and with the other
turn the upper part of the spool holder (8) anti-clockwise.
▪
Extract the empty spool and clean the inside of the spool holder carefully removing all dust
and grass residues.
▪
Insert now the new spool in the motor fan and push the end of line through the lateral
holes provided on the motor fan.
▪
Mount again by turning the spool holder (8) clockwise into the motor fan
▪
Re-establish the length of the nylon line by pushing the head of spool holder and pull the
line ends out to the desired length (approx. 10 cm).
CAUTION! Under no circumstances wind extra line on the empty spool but
instead replace it with a new one, the same as the original. The use of line
with different characteristics to those of the original can permanently
damage the grass trimmer as well as annulling the terms of the guarantee.
9 TECHNICAL DATA
Rated Voltage
Rated Frequency
Rated Power
Rotation speed
Cutting width
Protection class
Line size
Cutting system
Copyright © 2024 VARO
POWXG6211TB
230-240V
50 Hz
250W
-1
12000 min
220mm
Class II
Ø1.2 mm
2 lines/tap and go
P a g e
| 7
EN
www.varo.com
