Operating instructions for
pro's pro® Hornet MT-
250
DESCRIPTION OF THE DEVICE:
Scope of delivery
The Hornet MT-250 is delivered in 2 boxes.
Dimensions box #1: approx 760*335*335 mm, weight approx 25.10 kg
Dimensions box #2: approx 470*210*300 mm, weight approx 6.56 kg
Box#1 contains:
•
1 base plate incl. clamping basket (turntable) with 6-point frame fixation
•
1 small box with accessories: This contains
a. 2 holding pliers (inside of the jaws coated with diamond powder)
b. 4 frame fixings
c. Screw for fixing the turntable
d. Allen key set
Box#2 contains:
• Electric drive MT-250 (with contoured pull system and Tip2Pull
function Precisely adjustable to +/- 0.1)
a.
AC/DC adapter (AC100-240V 50/60Hz / current output DC+24V/4A
b.
Including power cable (power supply 24V 96W)
c.
Allen key set
d.
Plate for raising the clamping cage including 4 mounting screws
page 4 / 12
