compliance with the current safety standards. Make sure
that the main switch on the rear side is in position,,0" or
the main supply cable is not plugged in. Connect the
welding cables to their polarity and in conformity with the
electrode manufacturer's data. Welding current circuit
should avoid any direct or indirect contact with the
protective cable, except for contact on the welded piece.
If grounding is deliberately done using the protective cable
on the welded piece, the connection has to be as short as
possible. The protective cable cross-section has to be
equal to that of the reverse welding cable as a minimum.
Both the cables should be connected to the welding piece
at the same point. Use the grounding terminal on the
machine or a grounding terminal nearby.
Any precautionary measures should be taken to prevent
stray currents. Check that the mains voltage is
corresponding to the machine input voltage.
Main supply cable connection: When mounting the plug,
care has to be taken to have the corresponding capacity
and the main cable yellow-green conductor being
connected to the grounding plug. The capacity of thermal
magnetic switch or fuses of the main supply line should be
more or equal to the machine- absorbed current I1.
The absorbed current l1 may be determined upon having
read all the technical specifications on the machine
according to main input voltage U1. The cross section of
any extension cables should correspond to the absorbed
current l1. The current supply shall be switched on using
the main switch on the machine rear side.
WARNING:
ELECTRIC SHOCKS MAY BE FATAL!
DO NOT TOUCH ANY CONDUCTIVE
PARTS!
DO NOT TOUCH ANY WELDING
CONNECTION OUTLETS WHEN THE
MACHINE IS ON!
NEVER TOUCH THE WELDING
MACHINE OR ELECTRODE AND THE
GOUND TERMINAL AT A TIME!
Select the current subject to the electrode diameter,
welding position and the welding seam. With welding
completed, keep in mind that the main switch has to be
turned off and the electrode removed from the holder.
Welding with WIG equipment (for tungsten welding in
protective atmosphere): ordering no. Güde 41690.
Caution! It is not possible with ordering no. 20045,
20054!
Before getting down to work, make sure that the right
gas is available.
Fe
steel
Al
aluminium
(not possible with this device)
V2A
premium steel
Connecting the device, proceed as described below:
-
Connect the gas hose to the gas fitting on the
corresponding bottle using a clip and connect to the
WIG equipment.
The WIG equipment plug connects to the
-
corresponding socket „Dinse" on the inverter
(negative pole).
Caution: At WIG-welding (using a tungsten electrode
in protection atmosphere), the grounding cable is the
All manuals and user guides at all-guides.com
ArCO2
Ar
ArO2
positive pole and the WIG package is the negative
pole.
-
Now, plug the grounding cable in a corresponding
socket (positive pole).
-
Sharpen the tungsten needle in perpendicular
direction to the grinding wheel and insert it in the
clamp. Ca 5 mm of the tungsten needle should
protrude from the ceramic nozzle in the front. (see
Fig. 1-4).
Now, turn the burner gas valve on (ca ¼ turn) and
-
switch the device on WIG (if available)
Lighting: Now, set the ceramic nozzle edge sideward to
the material and swing the needle close the material
until the electric arc is formed.
Abb. 2 Hose with adapter
Product Description and Specification
The welding current supplies series GC-serial will supply
constant current and they are designed in an INVERTER
technique, equipped with heavy-duty and reliable
components and may be used for bar electrodes and for
protective atmosphere tungsten electrode welding.
EU DECLARATION OF CONFORMITY
We,
Güde GmbH & Co. KG
Birkichstraße 6
D-74549 Wolpertshausen
herewith declare that the following appliance complies with
the appropriate basic safety and health requirements of
the EU Directives based on its design and type, as brought
into circulation by us.
In case of alternation of the machine, not agreed upon
by us, this declaration will lose its validity.
Machine description: GC 100 PM
Article No. 20056
Datum/ Date/authorised signature:
Title of signatory:
Technical documentation:
Applicable EU Directives:
2004/108 EC
2006/95/EC
Applicable harmonised standards:
EN 60974-6:2003
EN 50445:2008
EN 60974-1:1998+A1:2000+A2:2003
EN 60974-10:2003
EN 61000-3-11
Place of certification:
Intertek Deutschland GmbH
Max-Eyth-Straße 14
70771 Leinfelden-Echterdingen
Deutschland
Reference number:
09SHW1878-01
Guarantee
The guarantee exclusively applies to material or
manufacturing defects. The original proof of purchase with
the purchase date must be submitted when lodging a claim
Managing Director
Mr Arnold
J. Bürkle FBL; QS
