in the guarantee period. The guarantee does not include
any unauthorised use, e.g. appliance overloading, violent
use, damage by a third party or foreign item. The failure to
follow the Operating Instructions and assembly instructions
and common wear and tear are not covered by the
guarantee either.
Residual risks and protective measures
Direct electrical contact
A faulty cable or plug can cause electric shock
dangerous to life.
Have any faulty cable or plug replaced by a specialist at all
times. Use the appliance only with connection fitted with a
safety switch against stray current (RCD).
Indirect electrical contact
Indirect local lighting
Insufficient lighting represents a high safety risk.
Sufficient lighting must always be ensured when working
with the appliance.
Thermal Protection - Overheat Protection and Protection
against Principal Current Supply Fault
The current supply will turn off in result of intervention of
the mains voltage control equipment and in result of
overheating (thermal switch on cooling elements).
Behaviour in case of emergency
Provide necessary first aid treatment corresponding to the
injury nature and seek qualified medical help as soon as
possible.
Protect the injured person from other injuries and calm
him/her down.
First aid kit must always be available in the place of
your work in case of accident in accordance with DIN
13164. Material taken out of the first aid kit needs to be
supplemented right away.
If help is needed, please provide the following details:
5.
Place of accident
6.
Accident nature
7.
Number of injured persons
8.
Injury type
Disposal
The disposal instructions are based on icons placed on the
appliance or its package. The description of the meanings
can be found in the "Marking" chapter.
Transport packaging disposal
The packaging protects the appliance against damage
during transport. The packaging materials are usually
selected depending on their environment friendliness and
disposal manner and can therefore be recycled.
Returning the packaging into circulation saves raw
materials and reduces waste disposal costs.
Parts of the packaging (e.g. foils, Styropor®) can be
dangerous to children. Risk of suffocation!
Keep parts of the packaging out of reach of children and
dispose them as quickly as possible.
Operating staff requirements
The operator must carefully read the Operating
Instructions before using the appliance.
Qualification
No special qualification is necessary for using the
appliance apart from detailed instruction by an expert.
All manuals and user guides at all-guides.com
Minimum age
The appliance can only be operated by persons over 16
years of age. An exception includes youngsters operating
the appliance within their professional education to
achieve necessary skills under trainer's supervision.
Training
Using the appliance requires only appropriate instructions
by a professional or reading the Operating Instructions. No
special training necessary.
Service
Do you have any technical questions? A claim? Do you
need spare parts or the Operating Instructions?
You will be helped quickly and without needless
bureaucracy at our webpage www.guede.com in the
Services part. Please help us be able to assist you. To be
able to identify your appliance when claimed, we need to
know its serial No., order No. and year of production. All
these details can be found on the type label. Enter the
details below for future reference.
Serial No.
Order No.
Year of production:
Tel.:
+49 (0) 79 04 / 700-360
Fax:
+49 (0) 79 04 / 700-51999
E-Mail:
support@ts.guede.com
FR
Soudeuse à inverseur Abb. 1
1. Régulateur du courant de soudage
2. Scories marteau avec une brosse
3. masque de soudage
4. Câble d´électrode (+)
9. Câble de de mesurage (-)
10. Principal
Données techniques
Connexion:
Protection:
Courant de soudage:
Tension de marche à vide:
Epaisseur du matériau rec.:
Gamme de réglage:
ED avec courant max.:
Classe d´isolement:
Poids approx.:
Consignes générales de sécurité
Si vous utilisez des appareils électrique, vous devez
respecter les consignes de sécurité de base afin
d'éviter le risque d'incendie, d'électrocution et de
blessure des personnes, ainsi que les consignes
suivantes :
Avant de mettre l'appareil en marche, lisez et respectez
toutes les consignes.
Conservez bien les consignes de sécurité.
230V~50 Hz
2,1 kVA
16 A
85 V
0,8-5 mm
10-80 A
80 A~30%
65 A~60%
50 A~100 %
IP21S
4,7 kg
