Refilling oil
To ensure that the tool remains operational for a long time, the tool
must have a sufficient fill of pneumatic oil.
You have the following options:
♦
Attach a maintenance unit with an oiler to the compressor.
♦
Install an add-on oiler in the compressed air line or the com-
pressed air tool.
♦
Add 3–5 drops of pneumatic oil into the connector nipple
after every 15 minutes of operation.
♦
When opening the oil container
cap nut from the container. Use a pair of long-nosed pliers or a
similar implement to remove the internal pipette.
♦
Turn it 180°, replace it and screw it back in place with the union nut.
♦
Use a needle or similar tool to poke a small hole into the tip of
the pipette to release the oil.
Connecting to a compressed air source
NOTE
►
Before connecting the compressed air source,
–
the correct working pressure (3–6,3 bar) must be fully
reached, and
–
make sure that the trigger is in the upper position.
►
Use only connection hoses with an internal diameter of at least
9 mm.
►
Use only filtered, lubricated and regulated compressed air.
♦
Screw the connector nipple
connection with the aid of a 14 mm open-end wrench.
♦
Attach the tool to a compressor by connecting the connector
nipple
with the supply hose of the compressed air source.
PDSS 16 A1
for the first time, remove the
into the air inlet
GB │ IE
. Tighten the
│
47
■
