4. Dip switch setting
Dip switch
How to reach the P.C. board
Remove the flat-top screw on the bottom of the back case.
Raise the bottom of the control unit, and now remove the unit by sliding it
upward.
The P.C. board on the back of the control unit is now visible.
Do not force the bottom of the control unit open. Doing so may
NOTE
damage the notch at the top and make it impossible to install the
control unit.
PCB of the control unit
