The following instructions are intended for a quali ed tter
to guide him/her along the installation, adjustment and
technical maintenance procedures as correctly as possible
and in full compliance with the applicable norms in force.
Important : unplug the hob before all operations.
Installation
•
This hob can be built into a worktop simply by cutting
out the corresponding slot.
•
The worktop must be made with a material designed
to withstand a temperature of approximately 100°C.
•
The hob should be positioned at least 40 mm away
from the back wall or any other vertical surface in order
to allow for correct ventilation and to prevent the
surfaces around the appliance from overheating.
Installation and fastening
Fastening
Very important: It is vital that you ensure the glass
ceramic hob is built into a perfectly flat supporting surface.
Deformations due to improper fastening could alter the
characteristics of the hob and compromise its performan-
ce.
The fastening springs are fastened by screws (see
diagram).
It is vital that these screws be kept accessible at all
times.
Insert the hob into the cut-out slot, applying pressure all
along the perimeter of the hob frame so that the latter
adheres fully to the worktop.
Distance to
keep between the
cut-out slot and
the cabinet
19
REAR SPRING ASSEMBLY
HOB FROM BELOW
FRONT OF HOB
KITCHEN
WORKTOP
