PerfectCharge
Set float voltage
You can use the DIP switches S3 and S4 to set the float voltage in the U phase (float).
S3
ON
OFF
ON
OFF
Set charging mode
!
WARNING! Danger of explosions!
Use only the charging mode appropriate for your battery type. If neces-
sary inquire at a specialist workshop.
You can set the charger mode using the S5 and S6 DIP switches.
S5
ON
OFF
ON
OFF
EN
All manuals and user guides at all-guides.com
S4
ON
13.8 V
ON
13.5 V
OFF
13.2 V
OFF
S6
Charger Mode
ON
IU0U- charging
Refer to chapter "Battery charging function" on
page 16.
ON
Constant voltage 1
The battery charger works as a constant voltage
source, where the value of the voltage corresponds
to the set charging end voltage.
OFF
Constant voltage 2
The battery charger works as a constant voltage
OFF
source, with the value of the voltage corresponding
to the set floating voltage.
Use charging converter
Float voltage
12 V
24 V
27.6 V
27.0 V
26.4 V
21
