8. Operation
LED indicators
Input Voltage Level LED
LED status
Red
Orange
Green
Orange
Red
Output Load Level LED
LED status
Green
Orange
Red
Status LED
Led indication
Green
Red (+ audible beep)
All manuals and user guides at all-guides.com
DC 12 V
< 11.0 V
11.0 ~ 11.5 V
11.5 ~ 15.0 V
15.0 ~ 15.5 V
>15.5 V
Power
0 – 100%
100 - 115%
> 115%
Meaning
Power OK
Over Load
Protection
DC 24V
< 22.0 V
22.0 ~ 23.0 V
23.0 ~ 30.0 V
30.0 ~ 31.0 V
>31.0 V
What to do?
Normal operation
Reduce the load and/or check the
AC wiring for possible short
circuits. Then reset the inverter
manually by switching the main
switch off and on again.
