18
ENGLISH
Product code
General specifications
Output voltage
Output waveform
Nom. battery voltage
Cont. power at 40 °C, cos phi 1
Peak load
AC connection
Efficiency (Max)
Display/read-out
Dimensions, hxwxd
Weight
Approvals
Technical specifications
Technology
Low battery voltage, switches off at
Low battery voltage, switches on at
High battery voltage, switches off at
High battery voltage, switches on at
Input current (nominal load)
No-load power consumption (ON
mode)
No-load power consumption
(Energy Saving mode)
Min. DC fuse (slow blow)
Min. cable size
Harmonic distortion typical
Cos phi
Temperature range (ambient
temp.)
Cooling
Protection degree
Protections
Options
Remote control
All manuals and user guides at all-guides.com
AC Master 12/700-230
28010700
200/220/230/240 Vac (± 3%) –
50/60 Hz (± 0,5%)
True sine
12 V
700 W
< 810 W (1 min)
< 1400 W
Continental European (SCHUKO)
• 91%
3 x LED
200 x 330 x 83 mm
2,6 kg
CE, Safety: EN60950-1, E-mark:
CISPR25, ISO11452-2, ISO7637-2,
EMC: EN55022, EN55024, EN61000-
3-2; -3-3, EN61000-4,2,3,4,5,6,8,11
High frequency
10,5 V
12,5 V
16,5 V
14,5 V
70 A
< 1,5 A @ 12 V
< 0,1 A @ 12 V
100 A
25 mm²
< 5%
All power factors allowed
-20 °C to 40 °C, derating > 40 °C
Fan
IP21 (if horizontally wall mounted)
Over temperature, over load, short
circuit, high/low battery voltage
Yes
AC Master 24/700-230
28020700
200/220/230/240 Vac (± 3%) –
50/60 Hz (± 0,5%)
True sine
24 V
700 W
< 810 W (1 min)
< 1400 W
Continental European (SCHUKO)
• 93%
3 x LED
200 x 330 x 83 mm
2,6 kg
CE, Safety: EN60950-1, E-mark:
CISPR25, ISO11452-2, ISO7637-2,
EMC: EN55022, EN55024, EN61000-
3-2; -3-3, EN61000-4,2,3,4,5,6,8,11
High frequency
21,0 V
25,0 V
33,0 V
29,0 V
35 A
< 0,8 A @ 24 V
< 0,06 A @ 24 V
50 A
16 mm²
< 5%
All power factors allowed
-20 °C to 40 °C, derating > 40 °C
Fan
IP21 (if horizontally wall mounted)
Over temperature, over load, short
circuit, high/low battery voltage
Yes
