RANGE MEASUREMENT
The device must be pointed directly at an object in
order to measure the range. Proceed as follows:
1. Press the main/trigger button. The range meter
is activated.
• The target mark appears.
When the main/trigger button is released, the target
mark continues to be displayed for approx. 6
seconds. If it is held depressed, the target mark is
displayed permanently.
Geovid HD-R (Typ 402-403).indb 33
All manuals and user guides at all-guides.com
2. Point the device at the object while the target
3. Press the main/trigger button again.
98
As long as the target mark is still lit, a new measure-
ment can be started at any time by pressing the
main/trigger button again.
The display shows:
– The object distance is less than 10 meters/yards,
– The range is exceeded, or
– The object is not sufficiently reflective.
When the display goes out, the range meter switches
off automatically.
33
mark is lit.
a. The target mark goes out briefly during the
measurement.
b. The measured value is displayed.
when
- - -
or
