TFA_No. 31.1066_Anleitung
Professional thermo-hygrometer
• Small parts can be swallowed by children (under three
years old).
• Batteries contain harmful acids and may be hazardous
if swallowed. If a battery is swallowed, this can lead to
serious internal burns and death within two hours. If
you suspect a battery could have been swallowed or
otherwise caught in the body, seek medical help imme-
diately.
• Batteries must not be thrown into a fire, short-circuit-
ed, taken apart or recharged. Risk of explosion!
• Low batteries should be changed as soon as possible
to prevent damage caused by leaking. Make sure the
polarities are correct. Never use a combination of old
and new batteries together, nor batteries of different
types. Remove the batteries if the device will not be
used for an extended period of time. Avoid contact with
skin, eyes and mucous membranes when handling
leaking batteries. In case of contact, immediately rinse
the affected areas with water and consult a doctor.
CAUTION
• Unauthorised repairs, alterations or changes to the
product are prohibited.
• Do not expose the device to extreme temperatures,
vibrations or shocks. Protect it from moisture, sand,
dirt and dust.
• To avoid damage to the sensor, do not remove the pro-
tective cover or insert sharp object through the ventila-
tion slots.
• Clean the device with a soft damp cloth. Do not use
solvents or scouring agents.
5. Elements
A: Display (Fig. 1):
A 1:
MAX/MIN values
A 2:
Battery symbol
A 3:
Temperature
A 4:
Humidity
B: Buttons (Fig. 1):
B 1:
MAX/MIN button
12
17.12.2024
11:14 Uhr
Professional thermo-hygrometer
B 2:
B 3:
C: Housing (Fig. 2):
C 1:
C 2:
C 3:
6. Getting started
6.1 Insert the batteries
• Open the battery compartment by pressing the notch
• All LCD segments will be displayed and the backlight
• Close the battery compartment.
• The device is ready for use. The temperature and
7. Operation
7.1 Backlight
• Press any button to activate the backlight for the set
7.2 ON/OFF/HOLD button
• To switch the device off and on again, press and hold
• To activate the HOLD function, briefly press the
• HOLD appears on the display.
• The actual temperature and humidity remain on the
• To deactivate the HOLD function, press the ON/OFF/
7.3 °C/°F/SET button
• Press the °C/°F/SET button to change between °C (Cel-
Seite 7
ON/OFF/HOLD button
°C/°F/SET button
Suspension device
Battery compartment
Protective cover for the sensor
with your thumb and then lift the lid. Insert two new AA
1,5 V batteries. Make sure the polarities are correct.
will turn on for a short moment.
humidity appear on the display.
lighting duration.
the ON/OFF/HOLD button for 3 seconds.
ON/OFF/HOLD button while the backlight is switched
on.
display.
HOLD button again.
sius) or °F (Fahrenheit) as temperature unit while the
backlight is switched on.
13
