Connection with adapter
Procedure (Fig. A)
1. Fit the adapter (1) to the extension
arm (4) or main pipe (5) (Bayonet
locking device: plug and turn).
2. Only when mounting on the ex-
tension arm: Screw the coupling
nut (3) onto the adapter.
3. Connect the device to the spray
gun of the PARKSIDE pressure
washer (Bayonet locking device:
plug and turn).
4. Screw the coupling nut (2) of the
adapter onto the spray gun.
Detaching (Fig. A)
1. Unscrew the coupling nut (2) on
the adapter (1).
2. If necessary, loosen the coupling
nut (3) on the extension arm (4).
3. Unscrew the adapter from the
spray gun and extension arm (Bay-
onet locking device: push, turn
and pull).
Operation
Working instructions
WARNING! Risk of injury! Be
aware of the recoil force when the
water jet commences. Ensure you are
standing firmly and holding the spray
gun firmly. Otherwise there is a risk of
injuring yourself or other people.
• Do not activate the high-pressure
jet of your pressure washer until
the device is in contact with the
surface to be cleaned.
• Always hold the device by the
handle (8) when cleaning walls.
• Do not guide the device over
freestanding corners.
• The device is not suitable for
scouring or scrubbing.
•
CAUTION! Damage to the spray
nozzle. Sweep open spaces before
using the device.
• Only use cleaning agents recom-
mended by PARKSIDE (e.g. W5
URM 0.5 l).
Pressure control
Procedure (Fig. C)
You can regulate the pressure of the
emerging water jet by turning the
pressure control (9). The rotation
speed of the nozzles changes ac-
cordingly.
• Increasing the pressure: Turn the
pressure control in the direction ➕
• Reducing the pressure: Turn the
pressure control in the direction ➖
Cleaning,
maintenance and
storage
WARNING! Risk of injury due to
unintentional start-up. Protect your-
self when performing maintenance or
cleaning work.
You should have any repair and main-
tenance work that is not described in
these instructions carried out by our
Service Centre. Only use original re-
placement parts.
Cleaning
• Always keep the product clean.
• Clean the device with a soft brush
or a slightly damp cloth.
• Do not use any cleaning agents or
solvents.
Maintenance
• Grease the O-rings on the main
pipe (5) and extension arm (4) (e.g.
with plumber's grease).
