Please read and comply with these origi-
nal instructions prior to the initial opera-
tion of your appliance and store them for
later use or subsequent owners.
Safety instructions
Please observe the safety in-
structions of your high-pres-
sure cleaner.
Only trigger the high-pres-
sure jet at the high-pressure
gun if the T-Racer is located
on the surface to be cleaned.
There must be no persons in
the immediate vicinity of the
cleaning head.
Beware of the recoil! Ensure
a stable position and firmly
hold the high-pressure gun
with the extension tube.
Upon completion of the
cleaning operation, switch off
the high-pressure cleaner.
When working on the T-Rac-
er, disconnect it from the
high-pressure gun as well.
Maximum water temperature
60 °C (please observe the in-
structions for your high-pres-
sure cleaner).
Description of the Appliance
When unpacking the product, make sure that no acces-
sories are missing and that none of the package con-
tents have been damaged. If you detect any transport
damages please contact your dealer.
Illustration
1
Casing
2
Handle
3
Twist grip Power (for adjustment of the cleaning
pressure)
4
Bayonet connection with union nut
5
Extension tubes (two tubes)
6
Rotor arm
7
High-pressure nozzles (2x)
6
All manuals and user guides at all-guides.com
The T-Racer is ideally suited for the cleaning of floor
and wall surfaces made of different materials such as
wood, plastic, concrete, tiles, and natural stone. Use the
T-Racer for private households only.
The T-Racer can be used with the provided devices. For
the use with another device, the high-pressure nozzles
must be adapted to the high-pressure cleaner used.
High-pressure cleaner with nominal voltage (p)
lesser than 13 MPa (130 bar)
eg: K 2 – K 5, Kärcher 201 – Kärcher 560
Use grey high-pressure nozzles.
High-pressure cleaner with nominal pressure (p) of
13 MPa (130 bar) to 16 MPa (160 bar)
e.g.: K 6 – K 7, Kärcher 600 – Kärcher 770
Use yellow high-pressure nozzles.
Suitable KÄRCHER high-pressure nozzles can be pur-
chased in specialist shops.
Note: Always use Kärcher water filter (order no. 4.730-
059.0) during suction operations of the high-pressure
cleaner.
Do not operate the pressure washer at the Eco level if
you wish to achieve an optimum cleaning result.
Fasten the T-Racer to the high-pressure gun using the
extension pipes.
Illustration
1
2
3
Repeat this process even for the other joints.
Tips for cleaning
Adjust the twist grip "Power" in accordance with the
Illustration
Do not run over protruding corners!
– 1
EN
Proper use
Symbols
DANGER
Do not reach under the edge of the T-Racer
during operation!
HARD
For sturdy surfaces (e.g. tiles, concrete,
stone).
SOFT
For sensitive surfaces (e.g. wood).
Application
Cleaning floor surfaces
Press the extension pipe into the bayonet catch of
the T-Racer.
Turn it by 90° until it locks into place.
Tighten the union nut.
Outdoor surfaces should be swept before the T-
Racer is used to avoid damaging the high-pressure
nozzles.
Prior to use on sensitive surfaces (e.g. wooden sur-
faces), test the product on an imperceptible spot, in
order to promptly detect any changes in the sur-
face.
The T-Racer is not suited for scouring or scrubbing!
Guide the T-Racer over the surface without effort.
Do not remain at one spot; always keep moving
during cleaning.
surface to be cleaned.
CAUTION
