The heater has to preferably be positioned at and permanently connected to an electric socket. This connection
may only be made by a qualified electrician and, for that reason, is not described here.
In this booklet, for reasons of safety, use with a plug should be assumed; when there is a permanent
connection, any passages about the plug do not apply.
Drill 2 holes in the wall at the chosen location with an 8 mm drill bit: make sure these holes are horizontal and 38.5
mm apart. Insert plugs and screws into the holes. Allow the screws to stick out by 10 mm. Hook the heater over the
screws using the hanging eyes, then pull downwards and slide to the left.
Check whether the heater is secured to the wall; if necessary insert the screws a little further into the plugs.
Attach the heater using the materials supplied (see
diagram). Place the bracket on top of the heater, in the
centre (see diagram 2) with the short side against the wall.
Mark the location of the hole on the wall and remove the
Using for the first time and Operation
Unroll the electrical cable entirely and insert the plug into a suitable 220/240V socket: the „voltage‟ indicator lamp
(HOLD) will light up.
Press the main switch on
Press the ON/OFF button: the fan will begin to rotate and the fan indicator lamp (FAN) will light up.
By pressing the MODE button one or more times, you can set the heater to half of full power or select just fan. The
indicator lamp for the chosen mode will light up as follows:
I = 1000 Watt heating (half power)
II = 2000 Watt heating (full power)
FAN = just ventilation
Press the ON/OFF button again in order to switch the heater off. When you have been using the device to provide heat, it
will cool off for 30 seconds before switching off entirely. During cooling, the FAN indicator lamp will flash on and off. Once
the cooling period has come to an end and the 'FAN‟ signal light has gone off, press the main switch to turn off and
remove the plug from the socket. The signal light „voltage‟ will continue to be illuminated until the main switch has been
released.
Timer:
The heater is equipped with a timer which can be used to set a specific operational period. Press the timer button
(TIMER) once you have selected a particular mode: by pressing once, you are setting a working time of half an hour;
each time you press again, half an hour will be added, up to a maximum of 7.5 hours. The corresponding indicator lamps
will light up:
0.5h
1h
0.5h + 1h
And so on up to a maximum of 7.5 hours.
Once the set period has passed, the heater will switch off automatically.
The mode can be changed during operation. If you wish to turn off the device before the set time has been reached,
simply press the ON/OFF button. The heater will now switch off, after any 30 second cooling off period.
Remote control
The heater comes with a remote control with 4 buttons:
TIMER
1000W
2000W
heater. Drill a hole at the
marked spot and insert a
plug. Now hang the heater in
place and screw the bracket
to the wall, as shown in the
diagram. The heater is now
installed.
=
0.5 hours
=
1 hour
=
1.5 hour
ON/OFF
This is used to switch the heater on or off. The fan begins to
rotate and the fan lamp lights up.
Timer button: use this to set an operational period (see above)
Half power. If you press this button while the heater is in operation, it
will heat at half power (1000W).
Full power. If you press this button while the heater is in operation, it
will heat at full power (2000W).
