Stopping the alarm / Snooze function
• When the alarm is triggered, the alarm symbol (3) starts
ashing and an alarm signal sounds.
• Press the alarm clock button (9) to stop the alarm.
Otherwise, it ends automatically after 4 minutes.
Note - Snooze function
• During the alarm signal, press the SNOOZE / LIGHT
button (10) to activate the snooze function. The alarm
clock symbol (3) starts to ash on the display. The alarm
signal is interrupted for 4 minutes and then triggered
again.
5.5 Backlight
• Press the SNOOZE/LIGHT button (10) to illuminate the
display for around 5 seconds.
Note - Backlight
• Constant illumination of the display is not possible.
5.6 Projection
Activation / deactivation:
Power supply -> batteries:
• when powered by the batteries, projection is switched off.
• If you press the SNOOZE / LIGHT button (10), the display
is projected onto the wall/ceiling for approx. 5 seconds.
Power supply -> Power supply unit:
• the projection is permanently switched on when power is
supplied via the power supply unit.
Projection setting
• Turn the projection arm forwards / backwards to project the
display onto the desired wall / ceiling.
• Turn the wheel (7) to adjust the sharpness of the projection.
• Press the TEMP / FLIP button (A) to rotate the projection
by 180 degrees.
• Two projection modes are possible:
- Time
- Time / indoor temperature
• Press and hold the TEMP / FLIP button (A) to call up
the alternating display mode for the time and indoor
temperature.
6. Care and maintenance
Only clean this product using a lint-free, slightly damp cloth
and do not use any harsh cleaners. Ensure that no water is
able to enter the product.
Note
Disconnect the device from the mains before cleaning and
during prolonged periods of non-use.
6
7. Warranty disclaimer
Hama GmbH & Co KG assumes no liability and provides no
warranty for damage resulting from improper installation/
mounting, improper use of the product or from failure to
observe the operating instructions and/or safety notes.
8. Technical data
Power supply
Measuring range -
Temperature
9. Declaration of conformity
Hama GmbH & Co KG hereby declares that
the radio equipment type [00222206] is in
compliance with Directive 2014/53/EU. The
full text of the EU declaration of conformity is available at
the following Internet address: https://support.hama.
com/00222206
Frequency bands
Speci cations according to Regulation (EU)
2019/1782
Brand name, commercial
register number,
Address
Model identi er
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average e ciency during
operation
E ciency at low load
Power consumption at zero load 0.10W
"Hvar" radio alarm clock
Power supply unit or 3.0 V, 2 x
AAA battery
0°C to +50°C
32°F to 122°F
77.5 kHz
Hama, HRA12159,
Dresdner Str. 9
86653 Monheim,
Germany
HX075-0501000-
AG-001
100–240 V
50 / 60 Hz
5.0 V DC / 1.0 A / 5.0 W
73.6%
65.9 %
