6.
Activate the sound approximately every 10 seconds. If the
glass is within range, the flashing LED will latch for
2.5 sec. At the same time the alarm relay is opened so
that the appropriate detection line on the alarm control unit
will trip.
Low-frequency response testing
Important:
This test verifies that the detector will respond to
lower frequencies. However, it is not a range check.
1.
To enter this mode while in the high-frequency test mode,
press the test button (SW2) a second time. The LEDs will
now flash alternately at a slower rate.
2.
A sharp blow of the hand or other firm object to a framed
hollow wall, ceiling or door will cause the flashing LEDs to
latch for 2.5 sec. and the alarm relay to open.
The test mode lasts 5 minutes after which the detector
automatically resets to the normal operation mode. To
manually exit the test mode, press the test button until the
LEDs stop flashing.
Functional test in normal run mode
Important:
This test is not a range check.
The detector must be in the normal run mode with the cover in
place on the detector.
Hold the GS905 tester directly against the glass surface to be
protected while aiming the loudspeaker towards the detector.
Set the tester mode selection switch to Continuous.
The tester automatically produces a loud simulated glass break
sound every 5 seconds.
Simultaneously make sharp blow of the hand or other firm
object to a framed hollow wall, ceiling or door near to or
adjacent to the unit to send the low frequency signal.
This should trigger an alarm.
Specifications
Input voltage:
Max ripple, p-p
Voltage monitoring
Current consumption:
Standby, no status LED
Standby, with status LED
Alarm, with alarm LED no
status LED
Alarm, with latched alarm LED
and status LED
Alarm output:
Semiconductor relay
Contact load rating
Series resistance
Tamper contact
Sensitivity
Max. range
Area of the surface to be monitored
Volume of the room to be monitored
P/N 1052697 (ML) • REV H • ISS 21NOV24
9 to 15 VDC
2 V
6.4 V ±0.4 V
12 mA
14 mA
9 mA
15 mA
Opens on alarm
100 VDC, 120 mA
35 Ω
100 VDC, 500 mA
Automatic adjustment
8.5 m radius
0.3 x 0.3 m min., 6 x 6 m max.
22 m³ min., 245 m³ max.
Recommended glass thickness:
Plate
Tempered
Wired
Laminated
Environmental class II
Regulatory information
PLACED ON THE MARKET BY:
Manufacturer
Carrier Fire & Security Americas Corporation Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
THESE PRODUCTS ARE INTENDED FOR SALE
and disclaimers
TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
"AUTHORIZED DEALER" OR "AUTHORIZED
RESELLER", IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE
AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
Certification
Approved for UK Government Use, for details
contact CPNI (tested in applications with a
maximum ceiling height of 4 metres).
REACH
Product may contain substances that are also
Candidate List substances in a concentration
above 0.1% w/w, per the most recently published
Candidate List found at ECHA Web site.
Safe use information can be found at
https://firesecurityproducts.com/en/content/intrusi
on-intro
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
recyclethis.info
Contact information
www.firesecurityproducts.com or www.aritech.com
3 to 6 mm
3 to 6 mm
6 to 8 mm
6 to 8 mm
−10 to +55°C
