EN
Chemical safety
A high-density laser beam is used by the product to irradiate the material to be cut or engraved, so as
to heat up the material surface and vaporize the material without burning. But some materials may
release toxic and harmful smoke or gases at a high temperature. Therefore, precautions are required
for chemical safety during material processing.
Warning
Follow the safety precautions:
■
Do not engrave or cut any material that contains PVC or vinyl (processing plastics is not
recommended). These materials (and other materials containing chlorine/chloride) can generate
corrosive vapor that is extremely harmful to the human body and can cause damage to the product.
Any damage caused by engraving or cutting any material containing PVC or vinyl is not covered by the
Company's warranty.
■
Do not engrave or cut any unknown materials. Vaporization or melting of many materials, which
include but are not limited to PVC and polycarbonate, may release harmful smoke.
■
You are advised to use the product with xTool Purifier. If you use a purifier, check and maintain the
filters regularly to ensure proper operation of the purifier. If the kit you've purchased does not include
a purifier, you can purchase a purifier separately.
Fire safety
A high-density laser beam is used by the product to irradiate the material to be cut or engraved, so as
to heat up the material surface and vaporize the material without burning. But most materials are
inherently flammable and may be ignited to form an open flame that can burn down the product
(even if it is made of flame-retardant materials) and its surroundings. Experience shows that vector
cutting with a laser is most likely to produce an open flame. In particular, acrylic has proven to be
extremely flammable in vector cutting.
Do not leave the
product unattended
when it is working.
Danger
Read the following warnings and suggestions carefully:
■
Ensure that the area around the product is clean and neat and that the workspace is well-ventilated
so that the generated smoke can be discharged in time.
■
Do not place any flammable materials, explosives, or volatile solvents, such as paper, acetone,
alcohol, or gasoline, around the product. They may cause the spread of flames and increase the risk of
material ignition.
■
Do not leave the product unattended when it is working. If the product works with setting errors and
is left unattended for a long period of time, or if a mechanical or electrical fault occurs, a fire may be
caused.
■
Clean the product regularly. Excessive accumulation of residues and chippings from cutting and
engraving would increase the risk of fire. The internal working area needs to be cleaned periodically to
ensure that there is no residue or chipping inside the product.
■
Keep a fire extinguisher and perform regular maintenance and inspection of it.
■
When the laser machine cuts or engraves flammable materials at low speed and high power, the
materials are prone to be ignited to form an open flame. If an open flame occurs, please stop
processing in time.
■
Place and use the product in locations where children are not likely to be present.
Electrical safety
Caution
Follow the safety precautions:
■
Do not open any access panel on the product when the product is connected to the power supply.
Accidental contact with the power supply may cause injury.
■
Do not touch any electronic area with your hands or other tools when the product is connected to a
power supply.
03
Keep combustible
materials away
from the product.
Use and maintenance
Caution
Follow the operating principles:
■
Check the product for damage every time before you use it. Do not operate it in any way when any
damage or defect is found.
■
Place and use the product on a stable, flat, and non-flammable surface. Keep the workspace clean
and neat.
■
Do not disassemble the product or change its structure in any way without authorization. Do not
modify or decompile its operating system.
■
Do not leave the product unattended during operation. When the product is working, pay attention
to whether it is working properly and what the indicators show by light.
■
Keep the inside of the product clean. Residues and chippings accumulated during cutting and
engraving are dangerous and may cause a fire. Clean the chippings and residues inside the work area
regularly.
■
The machine works properly at the temperature of +10°C to +30°C and can be stored properly at the
temperature of –10°C to +60°C. Do not operate it at a temperature lower than 0°C.
■
Cut off the power before maintaining the product.
■
This product is not user-serviceable. It must be returned to the factory or repaired by authorized
professionals.
■
Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
Warning and instruction signs
On the product, the warning and instruction signs are labeled where physical injuries or damage to
the product may be caused before and/or during operation. If a sign is damaged or lost, replace it
immediately. You can use the following template to print the sign you need.
LASER
APERTURE
Laser specifications
Wavelength
1.5 mrad (IEC 60825-1 Default (simplified)
1064 nm ± 5 nm
evaluation C6=1)
Working laser
1.5 mrad (IEC 60825-1 Default (simplified)
455 nm ± 5 nm
evaluation C6=1)
CLASS 4 LASER PRODUCT
Maximum output power: 10 W
Wavelength: 1064 nm ± 5 nm, 650 nm ± 5 nm, 455 nm ± 5 nm
Classification to IEC 60825-1:2014
DANGER - CLASS 4 VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EYE OR
SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION.
V1.0_D1.1.1_KS010636000
Beam divergence
Maximum power output
2 W
10 W
EN
